5. PARAMETERS
Class No. Symbol Name and Function
Initial
Value
Unit
Setting
Range
Control
Mode
23 FFC Feed forward gain:
Used to set the fee forward gain.
When it is set to 100%, droop pulses will not be generated in
constant-speed operation. Note that sudden acceleration/deceleration
will increase overshoot.
When setting this parameter, always set auto tuning (parameter No.
2) to
″ No ″
0 % 0
to
100
P
24 ZSP Zero speed:
Used to set the output range of the zero speed signal (ZSP).
50 r/min 0
to
10000
P x S x T
0 Analog speed command maximum speed:
Used to set the speed at the maximum input voltage (10V) of the
analog speed command (VC).
Set 0 to select the rated speed.
0
r/min 1
to
10000
S
0
25 VCM
Analog speed limit maximum speed:
Used to set the speed at the maximum input voltage (10V) of the
analog speed limit (VLA).
Set 0 to select the rated speed.
0
r/min 1
to
10000
T
26 TLC Analog torque command maximum output:
Used to set the output torque at the analog torque command voltage
(TC =
± 8V) of +8V on the assumption that the maximum torque is
100[%]. For example, set 50 to output (maximum torque × 50/100) at
the TC of +8V.
100 % 0
to
1000
T
27 *ENR Encoder output pulses:
Used to set the number of output pulses per encoder revolution
output by the servo amplifier.
4000 pulse 5
to
16384
P x S x T
Internal torque limit 1:
Set this parameter to limit servo motor-generated torque on the
assumption that the maximum torque is 100[%]. When 0 is set,
torque is not produced.
T
Internal torque limit 1:
Set this parameter to limit servo motor-generated torque on the
assumption that the maximum torque is 100[%].
When 0 is set, torque is not produced.
Across
TL-SG
Torque Limit
Open Internal torque limit 1 (Parameter No. 28)
Torque limit relationship Valid torque limit
Analog torque limit < internal torque limit 1 Analog torque limit
Analog torque limit > internal torque limit 1 Internal torque limit 1
Short
E
xp
ansio
n p
aram
ete
rs
28 TL1 100 % 0
to
100
P x S
