TM-499 Page 4
3-2. Dimensions, Weights, And Operating Angles
Dimensions
Height 20-3/4 in (527 mm) D
Width 22-3/4 in (577 mm)
Depth 31-1/4 in (793 mm)
B
Y Do not exceed tilt angles or engine could
be damaged or unit could tip
A 31-1/4 in (793 mm)
B
be damaged or unit could tip.
Y Do not move or operate unit where it
B 10-1/2 in (268 mm)
Y Do not move or operate unit where it
could tip.
C 13-45/64 in (348 mm)
A
D 22-3/4 in (577 mm)
A
E 1-3/4 in (44 mm)
C
F 19-1/2 in (495 mm)
G 13/32 in (10 mm) Dia.
15
°
15
°
Weight
4
G
15
°
1
° 15
°
15
°
Kohler: 265 lb (120 kg)
4
Holes
G
15
° 15
°
Honda Electric-Start Model:
278 lb (126 kg)
Honda Recoil-Start Model:
253 lb (114 kg)
802 096
Holes
Engine End
F
E
802 524-A
3-3. Fuel Consumption (Kohler-Powered Units)
198 575
50 HZ−AUX
50 HZ−WELD
HIGH IDLE
60 HZ−WELD
60 HZ−AUX
.
Fuel consumption at low idle
(2000 rpm): 0.2 U.S. gal/hr.
