ROUTER BITS
Router bits with 8 mm shank diameter
The router bits with two cutters are not suitable for
free-hand working with the router motor OFE 738
and the router and grinder motor FME 737
Version
Dia-
meter
mm
Overall
length
mm
Usable
length
mm
Radius
Angle
Order
no.
Straight bit
HSS
3
45
6
6.30930
HSS
4
47,5
9,5
6.30931
HSS
5
48,5
11,5
6.30932
HSS
6
48,5
16
6.30933
HSS
8
51
19
6.30934
HSS
10
48
20
6.30935
HSS
12
52
20
6.30993
HSS
14
48
20
6.30994
HSS
16
52
20
6.30995
HSS
18
20
6.30996
HSS
20
52
20
6.30997
Carbide
3
51
11
6.31630
Carbide
4
51
11
6.31631
Carbide
5
51
11
6.30936
Carbide
6
50
19
6.30937
Carbide
8
50
20
6.30938
Carbide
10
50
20
6.30939
Carbide
12
52
20
6.30940
Carbide
14
52
20
6.31632
Carbide
16
52
20
6.30941
Carbide
18
52
20
6.31633
Carbide
20
52
20
6.30942
Carbide
22
57
25
6.31634
Carbide
24
20
15
6.31635
Carbide
25
57
10
6.31636
Core-box bit
Carbide
9,5
45
7
4,75
6.31637
Carbide
12,7
40
9
6,35
6.30947
HSS
8
12
4
6.30943
HSS
12,7
9
6,35
6.30944
Core bit with pilot
HSS
23,8
52
16
9,5
6.30955
Core bits with
ball bearing
Carbide
31,7
51,95
14,3
9,5
6.31638
Carbide
38,1
57
16
12,7
6.31639
Version
Dia-
meter
mm
Overall
length
mm
Usable
length
mm
Radius
Angle
Order
no.
Beading bit
HSS
15,5
40
10
5
6.30949
Beading bits
with pilot
HSS
27,8
52
16
9,5
6.30974
Beading bits with
ball bearing
Carbide
25,4
52,2
13,5
6,35
6.31645
Carbide
28,7
53,2
15
8
6.31646
Carbide
31,7
55,2
16,5
9,5
6.31647
Carbide
38,1
57,2
19,7
12,7
6.31648
Rounding-over bits
with pilot
HSS
17,5
50
14
6,35
6.30998
HSS
23,8
52
16
9,5
6.30948
Rounding-over bit
with ball bearing
Carbide
25,4
51,2
12,7
6,35
6.31641
Carbide
28,7
15
8
6.31642
Carbide
31,75
54,63
15,88
9,53
6.31643
Carbide
38,1
59
19,7
12,7
6.31644
V-groove bit
HSS
11
14
60
6.30957
HSS
14
48
18
90
6.30958
Carbide
14
48
18
90
6.30959
Engraving bit
Carbide
11
55
20
60
6.31640
