5
2.9. Emergency operation
When the remote controller cannot be used
When the batteries of the remote controller run out or the remote controller
malfunctions, the emergency operation can be done using the emergency
buttons on the grille.
ADEFROST/STAND BY lamp
BOperation lamp
CEmergency operation switch (heating)
DEmergency operation switch (cooling)
EReceiver
Starting operation
• To operate the cooling mode, press the
button D.
• To operate the heating mode, press the button C.
Note:
• Details of emergency mode are as shown below.
Details of EMERGENCY MODE are as shown below. However, the tem-
perature control does not work for 30 minutes in test run and the unit is set
to continuous operation. The fan speed is set to High in test run and shifts
to Medium after 30 minutes.
Operation mode COOL HEAT
Set temperature 24°C 24°C
Fan speed med. med.
Airflow direction Horizontal 30° Downward 70°
Stopping operation
• To stop operation, press the
button D or the button C.
A B C D E
B A
D
C
3. Care and cleaning
Caution:
• Always turn off the power, first on the remote controller and then
the main switch, before cleaning or servicing the unit.
• When installing or removing the filter or the intake grille, do not
stand on an unsteady surface. You may fall and injure yourself. Be
also careful not to let dust fall into your eyes.
Dirty or clogged filters block the airflow and reduce efficiency. Very dirty
filters can damage the air-conditioner itself.
Intake grille removal
1Pull the catch on the intake grille in the direction indicated by the arrow
and it should open.
2Unhook the hinges to remove the intake grille from the grille.
Filter removal
1Open the intake grille.
2Release the catch on the center edge of the intake grille and pull the
filter forward to remove the filter.
A Catch B Grille C Intake grille D Filter
3.1. Cleaning the filters and the indoor unit
Cleaning the filter
• Clean the filter using a vacuum cleaner. If you do not have a vacuum
cleaner, tap the filter against a solid object to knock off dirt and dust.
• If the filter is especially dirty, wash it in lukewarm water. Take care to
rinse off any detergent thoroughly and allow the filter to dry completely
before putting it back into the unit.
Caution:
• Do not dry the filter in direct sunlight or by using a heat source,
such as an electric heater: this may warp it.
• Do not wash the filter in hot water (above 50°C), as this may warp
them.
• Make sure that the air filter is always installed. Operating the unit
without air filter can cause malfunction.
Cleaning the indoor unit
• Wipe the outside of the unit with a clean, dry, soft cloth.
• Clean off any oil stains or finger marks using a neutral household deter-
gent (such as dishwashing liquid or laundry detergent).
Caution:
Never use gasoline, benzene, thinner, scouring powder or any type of
non-neutral detergent, as these substances may damage the unit’s
case.
