Morphy Richards GrimeBuster steam cleaner - Manual (Page 4)

Setting up your steam
cleaner
Filling the boiler
1 Unscrew the filler cap ⁄ anti-clockwise.
2 Fill the boiler with a maximum of 1.8
litres of water by using the funnel Ï
provided. A
3 Do not use any detergents.
4 Screw the filler cap
⁄ clockwise until
finger tight. Do not overtighten.
Attaching hose and
accessories
1 Pull down the flap on the front of
machine socket. B
2 Insert the plug on the end of the hose ‰
into the machine socket › with the
button side facing up, and push firmly
until it clicks into place.
B
3 Attach the desired accessory, ie. large
floor brush Ì, triangular nozzle Û,
these need to be attached to the brush
connector
Ó before attaching it to the
extension tube or handle. Jet nozzle Ô,
window squeegee Ú to the extension
tube Ë or directly to the handle Â,
depending on the application. The
accessories vary per machine.
4 The round brush(es)  and Ò can be
attached to the jet nozzle.
5 Join the extension tubes together, slide
one tube into the other until it locks into
place
C.
6 Attach the tubes to the handle of the
hose. Slide the handle into the extension
tube until it locks into place
D.
• Some tasks may be easier with only one
tube fitted or none at all.
7 To connect the desired accessory
directly to the steam handle, slide the
handle into the accessory head until it
locks into place.
8 When using the large floor brush or the
triangular brush, the brush connector
needs to be fitted to the brush first, in
order to attach the same to the
extension tube.
4
A
B D
C
