MDLP2M (with Medium Throw Lens) - 4:3 Screen Size (1.33:1 Aspect Ratio)
Screen Diagonal
Screen Width
Screen Height
Minimum Distance
Maximum Distance
Inches
Centimeters
Inches
Centimeters
Inches
Centimeters
Inches
Centimeters
Inches
Centimeters
70
177.8
56
142.2
42
106.7
108-8/16
275.4
158-5/16
401.8
72
182.9
57-10/16
146.3
43-3/16
109.7
111-10/16
283.4
162-14/16
413.4
80
203.2
64
162.6
48
121.9
124-5/16
315.5
181-3/16
459.9
82
208.3
65-10/16
166.6
49-3-16
125.0
127-7/16
323.5
185-13/16
471.5
84
213.4
67-3/16
170.7
50-6/16
128.0
130-10/16
331.5
190-6/16
483.2
90
228.6
72
182.9
54
137.2
140-1/16
355.6
204-2/16
518.0
92
233.7
73-10/16
186.9
55-3/16
140.2
143-4/16
363.6
208-11/16
529.6
100
254.0
80
203.2
60
152.4
155-14/16
395.7
227
576.1
106
269.2
84-13/16
215.4
63-10/16
161.5
165-6/16
419.7
240-12/16
611.0
110
279.4
88
223.5
66
167.6
171-11/16
435.8
249-14/16
634.2
120
304.8
96
243.8
72
182.9
187-8/16
475.9
272-12/16
692.3
123
312.42
98-6-16
249.9
73-13/16
187.5
192-4/16
487.9
279-10/16
709.8
133
337.8
106-6/16
270.3
79-13-16
202.7
208
528.0
302-9/16
767.9
135
342.9
108
274.3
81
205.7
211-3/16
536.0
307-2/16
779.5
150
381.0
120
304.8
90
228.6
234-14/16
596.2
341-7/16
866.6
170
431.8
136
345.4
102
259.1
266-8/16
676.4
387-4/16
982.8
200
508.0
160
406.4
120
304.8
313-14/16
796.7
455-14/16
1,157.1
250
635.0
200
508.0
150
381.0
392-14/16
997.2
570-6/16
1,447.6
MDLP2L (with Long Throw Lens) - 4:3 Screen Size (1.33:1 Aspect Ratio)
Screen Diagonal
Screen Width
Screen Height
Minimum Distance
Maximum Distance
Inches Centimeters
Inches
Centimeters
Inches
Centimeters
Inches
Centimeters
Inches
Centimeters
60
152.4
48
121.9
36
91.4
203-13/16
517.4
203-13/16
517.4
70
177.8
56
142.2
42
106.7
157-11/16
400.2
238-4/16
604.7
72
182.9
57-10/16
146.3
43-3/16
109.7
162-4/16
411.8
245-2/16
622.1
80
203.2
64
162.6
48
121.9
180-9/16
458.3
272-10/16
692.0
82
208.3
65-10/16
166.6
49-3/16
125.0
185-3/16
469.9
279-8/16
709.4
84
213.4
67-3/16
170.7
50-6/16
128.0
189-12/16
481.6
286-6/16
726.9
90
228.6
72
182.9
54
137.2
203-8/16
516.4
307
779.3
92
233.7
73-10/16
186.9
55-3/16
140.2
208-1/16
528.0
313-15/16
796.7
100
254.0
80
203.2
60
152.4
226-6/16
574.5
341-7/16
866.6
106
269.2
84-13/16
215.4
63-10/16
161.5
240-2/16
609.4
362-1/16
918.9
110
279.4
88
223.5
66
167.6
249-4/16
632.6
375-13/16
953.9
120
304.8
96
243.8
72
182.9
272-2/16
690.7
410-3/16
1,041.2
123
312.42
98-6/16
249.9
73-13/16
187.5
279
708.2
420-9/16
1,067.4
133
337.8
106-6/16
270.3
79-13/16
202.7
301-14/16
766.3
454-15/16
1,154.7
135
342.9
108
274.3
81
205.7
306-8/16
777.9
461-13/16
1,172.1
150
381.0
120
304.8
90
228.6
340-13/16
865.0
513-6/16
1,303.1
170
431.8
136
345.4
102
259.1
386-10/16
981.2
582-3/16
1,477.7
200
508.0
160
406.4
120
304.8
455-4/16
1,155.5
685-6/16
1,739.6
250
635.0
200
508.0
150
381.0
569-12/16
1,446.0
857-6/16
2,176.1
300
762.0
240
609.6
180
457.2
684-3/16
1,736.5
1,029-6/16
2,612.6
