E
E-9
Specifications
Monitor
Specifications
Picture Tube Diagonal :
Viewable Image Size:
Radius:
Input Signal Video:
Sync:
Display Colors Analog input:
Synchronization Horizontal:
Range Vertical:
Resolutions Supported
Resolution based on horizontal
and vertical frequencies only
Active Display Area Horizont:
(Factory setting) Vertical:
Active Display Area
(Full scan)
Power Supply
Current Rating
Dimensions
Weight
Environmental Considerations
Operating Temperature:
Humidity:
Altitude:
Storage Temperature:
Humidity:
Altitude:
NOTE: Technical specifications are subject to change without notice.
Diamond Plus 73
Monitor
43cm(17inch)
41cm(16inch)
50000mm
ANALOG 0.7 Vp-p/75 Ohms
Separate sync. TTL Level
Horizontal sync. Positive/Negative
Vertical sync. Positive/Negative
Unlimited number of Colors
31kHz to 70kHz
55Hz to 120Hz
640 x 480 @60 to 120Hz
800 x 600 @55 to 110Hz
832 x 624 @55 to 105Hz
1024 x768 @55 to 87Hz....
1280 x 1024 @55 to 66Hz
310mm
232mm
325mm
243mm
AC 100-240V, 50-60Hz
1.5A @ 100-240V
403(W)x420(H)x420(D)mm
16.4kg
0˚C to +35˚C
30% to 80%
0 to 3000m
-20˚C to + 60˚C
10% to 90%
0 to 13700m
Notes
90˚ deflection, 0.25mm grille pitch,
medium short persistence phosphor,
aperture grille CRT, multi-layered, anti-
staticscreen coating, dark-tint screen.
Depends on the display card used.
Automatically
Automatically
Some systems may not support all
modes listed
Recommended resolution at 85 Hz for
optimal display performance.
Dependent upon signal timing used,
and does not include border area.
Dependent upon signal timing used,
and does not include border area.
