Motorola XU1100 - Manual (Page 20)

Getting
Star
ted
8
X
Installing AA Alkaline Batteries
Your radio can also use 4 AA batteries; alkaline cells provide up to 24 hours* of radio use.
Battery Meter
The battery meter located in the upper left corner of the display indicates how much
battery power you have remaining.
• Push the Ribbed Latch on the bottom of the
radio away from the battery door.
*Please refer to the diagram and Battery Life
on page 5.
• Slide and lift the battery door off.
• Place the AA batteries matching the
markings in the compartment.
• Slide and snap the battery door into place.
• Set the correct Battery Type, please refer to
page 16.
Battery
Type
3 Bars 2 Bars 1 Bar Flashing
d b c m
NiMH 100%-85% 85%-25% 25%-10% Final 10%
AA 100%-75% 75%-40% 40%-10% Final 10%
6881038B80.book Page 8 Wednesday, September 26, 2001 4:16 PM
