KD1800/KD6 A.C. GENERATOR — PARTS & OPERATION MANUAL — REV. #1 (06/16/05) — PAGE 23
KD1800/KD6 — INSTRUMENTATION
Power Outlets
The generator has the following single-phase 60 Hz, 120/
240 volt receptacles.
z
z
z
z
z
Single Phase
One Duplex NEMA (GFCI) 5-15R (120V, 15 Amp)
One Twist Lock NEMA L14-30R (120/240V, 30 Amp)
Main Circuit Breaker (2-Pole)
This 2-pole, 30 amp
main breaker protects the 120/240
output receptacle from short circuiting or overloading.
GFCI Circuit Breaker (Single-Pole)
This single-pole, 15 amp breaker protects the GFCI
receptacle from short circuiting or overloading.
GFCI Receptacle
Before connecting a load to the generator's GFCI receptacle,
push the "Test Button" on the front of receptacle before
connecting the load, to confirm that the receptacle is
functioning correctly.
Pre-Heat Lamp
Lights blue during engine start-up. Indicates that engine glow
plugs are being pre-heated. Light will go off after
approximately 10 seconds.
CAUTION :
When using a combination of dual
receptacles, total load should not exceed
the rated capacity of the generator set.
