PAGE 20 —KD1800/KD6 A.C. GENERATOR— PARTS & OPERATION MANUAL — REV. #1 (06/16/05)
Circuit Breakers
To protect the generator from an overload, a 2-pole, 30 amp,
main circuit breaker is provided. In addition a single pole,
15 amp breaker is provided for the G.F.C.I. receptacle. Make
sure to switch both circuit breakers to the "OFF" position
prior to starting the engine.
Extension Cable
When electric power is to be provided to various tools or
loads at some distance from the generator, extension cords
are normally used. Cables should be sized to allow for
distance in length and amperage so that the voltage drop
between the generator and point of use (load) is held to a
minimum. Use the cable selection chart (Table 3 ) as a guide
for selecting proper cable size.
KD1800/KD6 — PRE-SETUP (GENERATOR)
)
