NPort 5110 Series User’s Manual
Auto IP Report Protocol
D-2
You will then be able to develop your own programs to receive this information from the NPort.
Here is NPort’s Auto IP Report Protocol. Click on the following link to link to a specific example.
Auto IP Report Format
“MOXA”, 4 bytes
Info[0] Info[1]
...
Info[n]
Info [n]
Field ID
Length Data
Length
1
1
Variable, Length is “Length Field”
ID List
ID Value
Description
Length
Note
1
Server Name
Variable
ASCII char
2 Hardware
ID 2 Little-endian
3
MAC Address
6
6 bytes MAC address. If the MAC
address is "00-90-E8-01-02-03", the
MAC[0] is 0, MAC[1] is 0x90(hex),
MAC[2] is 0xE8(hex), and so on.
4
Serial Number
4, DWORD Little-endian
5 IP
Address 4,
DWORD
Little-endian
6 Netmask 4,
DWORD
Little-endian
7
Default Gateway
4, DWORD Little-endian
8
Firmware Version
4, DWORD Little-endian
Ver1.3.4= 0x0103040
9
AP ID
4, DWORD Little-endian
AP ID & Hardware ID Mapping Table
AP ID
Hardware ID
Product
0x80005110 0x5110
NPort
5110
0x80005000 0x0504
NPort
5410
0x80005000 0x0534
NPort
5430
0x80005000 0x1534
NPort
5430I
0x80000312 0x0312
NPort
5230
0x80000312 0x0322
NPort
5210
0x80000312 0x0332
NPort
5232
0x80000312 0x1332
NPort
5232I
0x80005610 0x5618
NPort
5610-8
0x80005610 0x5613
NPort
5610-16
0x80005610 0x5638
NPort
5630-8
0x80005610 0x5633
NPort
5630-16
