NPort 5110 Series User’s Manual Web Console Configuration
5-9
Port alias
Setting Factory Default Necessity
1 to 15 characters
(E.g., PLC-No.1) None Optional
“Port alias” is included to allow easy identification of the serial devices that are connected to
NPort 5110’s serial port.
Serial Parameters
ATTENTION
Check the serial communication parameters in your Serial Device’s user’s manual. You should
set up NPort 5110’s serial parameters with the same communication parameters used by your
serial devices.
Baud rate
Setting Factory Default Necessity
110 bps to 230.4 Kbps 115.2 Kbps Required
Data bits
Setting Factory Default Necessity
5, 6, 7, 8 8 Required
When the user sets Data bits to 5 bits, the Stop bits setting will automatically change to 1.5 bits.
Stop bits
Setting Factory Default Necessity
1, 1.5, 2 1 Required
Stop bits will be set to 1.5 when Data bits is set to 5 bits.
Parity
Setting Factory Default Necessity
None, Even, Odd, Space, Mark None Required
Flow control
Setting Factory Default Necessity
None, RTS/CTS, DTR/DSR, Xon/Xoff RTS/CTS Required
FIFO
Setting Factory Default Necessity
Enable, Disable Enable Required
NPort 5110’s serial ports provide a 16-byte FIFO both in the Tx and Rx directions. To prevent
data loss during communication, disable the FIFO setting when your serial device does not have a
FIFO.
Interface
Model Port Settings Factory Default Necessity
NPort 5110 1 RS-232 RS-232 Required
