Product Specifications
Maxtor D540X-4G 3-3
2GTHQTOCPEG 5RGEKHKECVKQPU
2J[UKECN &KOGPUKQPU
/1&'.5 ), ),
Seek Times (typical read, ms)
Track-to-Track 1
Average (normal seek) 11
Full Stroke (normal seek) 20
Average Latency (ms) 5.5
Controller Overhead (ms) <0.3
Rotation Speed (RPM ±0.1%) 5400
Data Transfer Speed (MByte/sec max)
To/From Interface
(Maxtor Ultra ATA/133, up to)
133
To/From Media (ID/OD up to nn.n, where
nn.n is the maximum transfer rate possible) 21.9/43.4
Sustained (ID/OD up to nn.n, where nn.n is
the maximum transfer rate possible) 17.8/35.9
Data Buffer Size (MB)/Type 2/SDRAM
Drive Ready Time (typical sec) 7.5
2#4#/'6'4 8#.7'
Height (maximum in mm) 26.1
Width (typical mm) 101.6
Length (maximum in mm) 147.0
Weight (maximum in kg) 0.580
