Product Description
2-2 Maxtor D540X-4G
Note: Maxtor defines 1 Gigabyte (GB) as 10
9
or 1,000,000,000 bytes of data.
Total accessible capacity varies depending on operating environment.
63.9-8 /+896/7
(WPEVKQPCN+PVGTHCEG
Maxtor hard drives contain all necessary mechanical and electronic parts to interpret
control signals and commands from an AT-compatible host computer. See Chapter 3
Product Specifications, for complete drive specifications.
The disk capacity is increased with bit density management – common with Zone
Density Recording. Each disk surface is divided into 16 circumferential zones. All
tracks within a given zone contain a constant number of data sectors. The number
of data sectors per track varies in different zones; the outermost zone contains the
largest number of data sectors and the innermost contains the fewest.
4GCF9TKVG /WNVKRNG /QFG
This mode is implemented per ANSI ATA/ATAPI-6 specification. Read/Write
Multiple allows the host to transfer a set number of sectors without an interrupt
request between them, reducing transfer process overhead and improving host
performance.
7NVTC&/# /QFG
Maxtor hard drives fully comply with the new ANSI Ultra DMA protocol, which
greatly improves overall AT interface performance by significantly improving burst
and sustained data throughput.
/WNVK YQTF &/# /QFG
Supports multi-word Direct Memory Access (DMA) mode transfers.
5GEVQT #FFTGUU 6TCPUNCVKQP
All Maxtor hard drives feature a universal translate mode. In an AT/EISA-class
system, the drive may be configured to any specified combination of cylinders,
heads and sectors (within the range of the drive's formatted capacity). Maxtor hard
drives power-up in a translate mode:
/1&'.5 %;. *& 526 /#: .$# %#2#%+6;
4G120J6 238,216 16 63 240,121,728 122.9GB
4G160J8 317,632 16 63 320,173,056 163.9GB
