Information Display Functions
• Driver’s Temperature
• Climate Control
• Clock/Trip Computer • Audio
• Bluetooth
® Hands-Free
• Outside/Passenger Temperature
nOTE: With defroster and floor vents or windshield defroster mode, the system
turns on the A/C compressor and selects the FRESH AIR mode. This helps defrost
the windows more efficiently by dehumidifying the air. The A/C compressor will
always be on in defroster mode, but the defroster (and floor) will deliver warm air
when the temperature dial is set to a warmer temperature and the engine warms up.
nOTE: If the rear AUTO button is pressed while the front A/C button is off, the rear
air conditioning operates only to circulate air. Setting the temperature to the maximum
high or low will not provide the desired temperature at a faster rate.
Automatic Climate Control
The driver and front passenger
seats can be warmed by pushing
the applicable seat warmer button
while the ignition is ON.
• Seat temperature increases as
the number of indicator lights
increases. Two lights equal
high, one light equals low.
• When the seat warmers are
not needed, push button until
indicator lights are off.
FrOnT SEAT WArMErS
Push to manually turn
air conditioning ON or
OFF while climate control
system is on.
Push to select the
desired airflow mode.
Push to display outside
temperature. Push and hold
for three seconds or longer
to switch from Fahrenheit
and Celsius or vice versa.
Push to turn climate
control system off.
Push to defrost
the windshield.
Push to defrost the
rear window.
Push to allow control from the
rear controls (indicator on).
Rotate dial to turn the
system ON and to select
the desired fan speed.
Push to allow separate
driver/passenger
temperature control.
Push to recirculate cabin air
to reduce outside odors and
improve cooling (indicator
on) or receive fresh air
(indicator off).
Automatic Climate Control Operation
1 Push AUTO to turn the front air conditioning on.
2 Rotate AUTO dial (driver’s temperature control) to the desired cabin
air temperature setting (shown in the Information Display above).
nOTE: Rotating fan control dial, or pushing the MODE button, or A/C switch,
or windshield defroster switch while in AUTO ON mode will cancel auto A/C.
Dual zone Operation
• To allow the passenger to independently control passenger side
temperature setting, rotate the DUAL dial (passenger’s temperature
control) or push the DUAL button. The DUAL indicator will
illuminate and passenger temperature setting will be displayed on
the Information Display.
• To turn off Dual Zone operation, push the DUAL button.
rear Climate Control Operation from Front Seats
1 Turn the front air conditioning on.
2 Push the REAR control button on the front
control panel (indicator on).
3 Selection of the airflow mode, airflow amount
and temperature will be automatically controlled
to the same setting as the front air conditioner.
Information Display
MODE
OFF
rEAr
OUTSIDE
TEMP
rEAr
FrOnT
DUAL
