8. ADVANCED SETUP
MAIN SETUP PAGE
1. HDD INFORMATION
2. DATE-TIME SETUP
3. DISPLAY SETUP
4. CAMERA SETUP
5. BUZZER SETUP
6. RELAY SETUP
7. SYSTEM SETUP
8. ADVANCED SETUP
MENU, ESC: EXIT, ENTER: RUN
ADVANCED SETUP PAGE
1. ALARM SETUP
2. MOTION SETUP
3. RECORD SETUP
4. PASSWORD SETUP
5. NETWORK SETUP
6. HDD FORMAT
7. FACTORY DEFAULT
8. SOFTWARE UPDATE
7. FACTORY DEFAULT
8. SOFTWARE UPDATE
6. HDD FORMAT
ADVANCED SETUP PAGE
1. ALARM SETUP
2. MOTION SETUP
3. RECORD SETUP
4. PASSWORD SETUP
5. NETWORK SETUP
2. ALARM DURATION
3. ALARM RELAY SETUP
4. ALARM POLARITY SETUP
MENU, ESC: EXIT: : MODIFY
1. ALARM FUNCTION
ALARM SETUP PAGE
1. Alarm function: ON / OFF. Alarm function on or off depends on alarm device includes in DVR system.
2. Alarm duration: 10 ~ 999. Alarm buzzer and record duration time.
ALARM RELAY SETUP
>ALARM 01 ~ ALARM 04: ON / OFF
Even choose on, but RELAY SETUPÆAlarm relay or relay function off, this function is still closed.
ALARM POLARITY SETUP
>ALARM 01 ~ ALARM 4: N.O. / N.C. / OFF
Press direction buttons up/down to choose items.
Press values change button to change values.
