Dimensions
Dimensions
The following dimensions can assist in determining the
best location for your C2300. There is additional informa-
tion on the next page pertaining to installing the C2300
into cabinets.
17-
1/2
"
44.45cm
6-
3/8
"
16.19cm
7 -
5/8
"
19.37cm
16-
1/2
"
41.91cm
3/16
"
0.48cm
13 -
1/4
"
33.66cm
17-
1/8
"
43.50cm
Front View of the C2300
Rear View of the C2300
Side View of the C2300
7 -
1/8
"
18.10cm
13/16
"
2.06cm
6-
9/16
"
16.67cm
10-
9/16
"
26.83cm
14-
1/2
"
36.83cm
2"
5.08cm
1-
15/16
"
4.92cm
