Philips Magnavox MWC24T5 User Manual
Page 76
20060325
1-19-3
T2202EL
D1224
LED SIR-563ST3F P
QPQPS1R563ST
D1229
ZENER DIODE MTZJT-7715B
QDTB00MTZJ15
D1230
ZENER DIODE MTZJT-7715B
QDTB00MTZJ15
D1231
ZENER DIODE MTZJT-7718A
QDTA00MTZJ18
D1237
ZENER DIODE MTZJT-776.8B
QDTB0MTZJ6R8
D1302
SWITCHING DIODE 1SS133(T-77)
QDTZ001SS133
D1303
SWITCHING DIODE 1SS133(T-77)
QDTZ001SS133
D1304
SWITCHING DIODE 1SS133(T-77)
QDTZ001SS133
D1305
CARBON RES. 1/4W J 15
Ω
RCX4JATZ0150
D1351
SWITCHING DIODE 1SS133(T-77)
QDTZ001SS133
D1419
SWITCHING DIODE 1SS133(T-77)
QDTZ001SS133
D1420
SWITCHING DIODE 1SS133(T-77)
QDTZ001SS133
D1603#
DIODE 1N5406
NDLZ001N5406
D1604#
DIODE 1N5406
NDLZ001N5406
D1605#
DIODE 1N5406
NDLZ001N5406
D1606#
DIODE 1N5406
NDLZ001N5406
D1607#
ZENER DIODE MTZJT-7724C
QDTC00MTZJ24
D1609#
SWITCHING DIODE 1SS133(T-77)
QDTZ001SS133
D1610
ZENER DIODE MTZJT-776.2B
QDTB0MTZJ6R2
D1611
SWITCHING DIODE 1SS133(T-77)
QDTZ001SS133
D1612
SWITCHING DIODE 1SS133(T-77)
QDTZ001SS133
D1613
FAST RECOVERY DIODE FE201-6
QDLZ00FE2016
D1614#
DIODE FR104-B
NDLZ000FR104
D1615
RECTIFIER DIODE 1N4005
NDQZ001N4005
D1616#
FAST RECOVERY DIODE FR202
NDWZ000FR202
D1617#
FAST RECOVERY DIODE FR202
NDWZ000FR202
D1618#
DIODE FR154
NDLZ000FR154
D1619#
DIODE FR104-B
NDLZ000FR104
D1620#
ZENER DIODE MTZJT-776.8B
QDTB0MTZJ6R8
D1621
SWITCHING DIODE 1SS133(T-77)
QDTZ001SS133
D1622#
SWITCHING DIODE 1SS133(T-77)
QDTZ001SS133
D1623
SWITCHING DIODE 1SS133(T-77)
QDTZ001SS133
D1624
SWITCHING DIODE 1SS133(T-77)
QDTZ001SS133
D1626
ZENER DIODE MTZJT-7736A
QDTA00MTZJ36
D1627
ZENER DIODE MTZJT-7722A
QDTA00MTZJ22
D1628
SWITCHING DIODE 1SS133(T-77)
QDTZ001SS133
D1634
ZENER DIODE MTZJT-778.2B
QDTB0MTZJ8R2
D1635
SWITCHING DIODE 1SS133(T-77)
QDTZ001SS133
D1636
SWITCHING DIODE 1SS133(T-77)
QDTZ001SS133
D1637
SWITCHING DIODE 1SS133(T-77)
QDTZ001SS133
D1640#
DIODE 1ZC36(Q)
QDLZ001ZC36Q
D1641#
ZENER DIODE MTZJT-7736A
QDTA00MTZJ36
D1645#
FAST RECOVERY DIODE FR202
NDWZ000FR202
D1646
DIODE FR154
NDLZ000FR154
D1657
SWITCHING DIODE 1SS133(T-77)
QDTZ001SS133
D1660
SWITCHING DIODE 1SS133(T-77)
QDTZ001SS133
D1663
ZENER DIODE MTZJT-776.2C
QDTC0MTZJ6R2
D1680
SWITCHING DIODE 1SS133(T-77)
QDTZ001SS133
D1682
SWITCHING DIODE 1SS133(T-77)
QDTZ001SS133
D1683
SWITCHING DIODE 1SS133(T-77)
QDTZ001SS133
D1684
SWITCHING DIODE 1SS133(T-77)
QDTZ001SS133
D1687
SWITCHING DIODE 1SS133(T-77)
QDTZ001SS133
D1688
SWITCHING DIODE 1SS133(T-77)
QDTZ001SS133
D1691
ELECTROLYTIC CAP. 100
µF/6.3V M
CE0KMASDL101
D1811
SWITCHING DIODE 1SS133(T-77)
QDTZ001SS133
D1812
SWITCHING DIODE 1SS133(T-77)
QDTZ001SS133
D1813
SWITCHING DIODE 1SS133(T-77)
QDTZ001SS133
ICS
IC1001
IC VIF/SIF M61116FP TF0G
QSZBA0SHT034
IC1201#
MICRO COMPUTER M3776AMCH-BA4GP
QSZAA0RHT099
IC1202
IC CAT24WC02WI-TE13
NSZBA0TBG007
IC1301#
VCD IC M61275FP-TF3H
QSZAD0RMB133
Ref. No.
Description
Part No.
IC1401
IC Y/C/A LA71205M-MPB-E
QSZBA0RSY037
IC1601#
PHOTOCOUPLER LTV-817C-F
NPEC0LTV817F
IC1682#
IC VOLTAGE REGULATOR 5V KIA7805API/P
NSZBA0SJY041
IC1701
IC HIFI LA72670BM-MPB-E
QSZBA0RSY039
IC1803
IC AN17812A
QSZBA0SMS017
COILS
L1031
PCB JUMPER D0.6-P5.0
JW5.0T
L1032
PCB JUMPER D0.6-P5.0
JW5.0T
L1033
INDUCTOR 150
µH-J-26T
LLAXJATTU151
L1202
INDUCTOR 0.10
µH-K-26T
LLAXKATTUR10
L1601#
LINE FILTER JLB2460
LLBG00ZXB012
L1872
INDUCTOR 47
µH-K-5FT
LLARKBSTU470
TRANSISTORS
Q1205
TRANSISTOR 2SC2785(F)
QQSF02SC2785
Q1206
PHOTO TRANSISTOR MID-32A22F
NPWZ1D32A22F
Q1221
RES. BUILT-IN TRANSISTOR KRA103M-AT/P
NQSZ0KRA103M
Q1350
NPN TRANSISTOR 2SC1627-Y (TE2.F.T)
QQSY2SC1627F
Q1401
TRANSISTOR 2SA1175(F)
QQSF02SA1175
Q1402
TRANSISTOR 2SA1175(F)
QQSF02SA1175
Q1403
TRANSISTOR 2SA1175(F)
QQSF02SA1175
Q1601#
MOS FET 2SK3561
QFWZ02SK3561
Q1602#
TRANSISTOR 2SC2120-O(TE2 F T)
QQS02SC2120F
Q1603
TRANSISTOR 2SC2785(F)
QQSF02SC2785
Q1604#
TRANSISTOR 2SC2785(F)
QQSF02SC2785
Q1605
TRANSISTOR 2SC2785(F)
QQSF02SC2785
Q1606#
TRANSISTOR 2SA950-O (TE2 F T)
QQS002SA950F
Q1607#
TRANSISTOR 2SC2785(F)
QQSF02SC2785
Q1609
TRANSISTOR 2SC2120-O(TE2 F T)
QQS02SC2120F
Q1613
TRANSISTOR KTC3199-GR-AT/P
NQS4KTC3199P
Q1614
TRANSISTOR KTC3199-GR-AT/P
NQS4KTC3199P
Q1681#
TRANSISTOR KTC3205-Y-AT/P
NQSYKTC3205P
Q1688#
TRANSISTOR KTC3205-Y-AT/P
NQSYKTC3205P
Q1701
TRANSISTOR 2SC2785(F)
QQSF02SC2785
Q1871
TRANSISTOR 2SA1175(F)
QQSF02SA1175
Q1872
TRANSISTOR 2SC2120-O(TE2 F T)
QQS02SC2120F
Q1873
TRANSISTOR 2SC3331(T)
QSC3331TNPAA
Q1874
TRANSISTOR 2SC3331(T)
QSC3331TNPAA
Q1875
RES. BUILT-IN TRANSISTOR KRA103M-AT/P
NQSZ0KRA103M
RESISTORS
R1002
CHIP RES. 1/10W J 220
Ω
RRXAJR5Z0221
R1003
CHIP RES. 1/10W J 220
Ω
RRXAJR5Z0221
R1032
CHIP RES. 1/10W J 100
Ω
RRXAJR5Z0101
R1033
CHIP RES. 1/10W J 390k
Ω
RRXAJR5Z0394
R1034
CHIP RES. 1/10W J 1.8k
Ω
RRXAJR5Z0182
R1037
CHIP RES. 1/10W J 180
Ω
RRXAJR5Z0181
R1038
CHIP RES. 1/10W J 1k
Ω
RRXAJR5Z0102
R1039
CARBON RES. 1/4W J 1k
Ω
RCX4JATZ0102
R1040
CHIP RES. 1/10W J 2.2k
Ω
RRXAJR5Z0222
R1041
CARBON RES. 1/4W J 15k
Ω
RCX4JATZ0153
R1042
CHIP RES. 1/10W J 15k
Ω
RRXAJR5Z0153
R1043
PCB JUMPER D0.6-P5.0
JW5.0T
R1049
CHIP RES.(1608) 1/10W 0
Ω
RRXAZR5Z0000
R1050
CHIP RES.(1608) 1/10W 0
Ω
RRXAZR5Z0000
R1053
CHIP RES. 1/10W J 1.5k
Ω
RRXAJR5Z0152
R1110
CHIP RES. 1/10W J 2.2k
Ω
RRXAJR5Z0222
R1111
CHIP RES. 1/10W J 2.2k
Ω
RRXAJR5Z0222
R1159
CHIP RES. 1/10W J 22k
Ω
RRXAJR5Z0223
R1160
CHIP RES. 1/10W J 10k
Ω
RRXAJR5Z0103
R1163
CHIP RES. 1/10W J 1.8k
Ω
RRXAJR5Z0182
R1164
CHIP RES. 1/10W J 1.8k
Ω
RRXAJR5Z0182
R1200
CHIP RES. 1/10W J 1k
Ω
RRXAJR5Z0102
R1201
CHIP RES. 1/16W G 4.7k
Ω
RRXAGR5Z0472
Ref. No.
Description
Part No.
