Philips Magnavox MWC24T5 - Manual (Page 46)

1-11-8 T2202SCM6
Main 6/6 Schematic Diagram < TV/VCR Section >
NOTE:
The voltage for parts in hot circuit is measured using
hot GND as a common terminal.
For continued protection against risk of fire,
replace only with same type 4 A, 125V fuse. CAUTION ! :
ATTENTION : Utiliser un fusible de rechange de m ê me type de 4A, 125V. 4A 125V
CAUTION !
Fixed voltage (or Auto voltage selectable) power supply circuit is used in this unit.
If Main Fuse (F1601) is blown , check to see that all components in the power supply
circuit are not defective before you connect the AC plug to the AC power supply.
Otherwise it may cause some components in the power supply circuit to fail.
VOLTAGE CHART (Power off mode)
Ref. No. 1 4
IC1601 25.7 1.2
Ref. No.
IC1682
Ref. No.
Q1601
Ref. No.
Q1221
Q1602
Q1604
Q1605
Q1606
Q1607
Q1609
Q1613
Q1614
Q1681
Q1688
2 3
24.7 0.3
1 2 3
3.2 0 1.7
S D G
0 162.8 1.9
E C B
5.2 5.1 4.6
0 1.9 0.3
6.7 24.7 7.3
0 7.9 0
8.5 8.5 7.8
0 7.7 6.6
5.9 8.2 6.5
0.8 4.2 1.4
0.9 4.2 1.4
0 3.3 0
0 3.3 0
