Philips Magnavox MWC24T5 User Manual
Page 75
20060325
1-19-2
T2202EL
C1428
CHIP CERAMIC CAP.(1608) B K 0.01
µF/50V
CHD1JK30B103
C1429
ELECTROLYTIC CAP. 47
µF/6.3V M H7
CE0KMAVSL470
C1430
CHIP CERAMIC CAP.(1608) B K 0.01
µF/50V
CHD1JK30B103
C1431
CHIP CERAMIC CAP. F Z 1
µF/10V
CHD1AZ30F105
C1432
ELECTROLYTIC CAP. 1
µF/50V M H7
CE1JMAVSL1R0
C1435
ELECTROLYTIC CAP. 1
µF/50V M H7
CE1JMAVSL1R0
C1436
CHIP CERAMIC CAP.(1608) B K 0.01
µF/50V
CHD1JK30B103
C1437
ELECTROLYTIC CAP. 22
µF/16V M H7
CE1CMAVSL220
C1438
CHIP CERAMIC CAP. F Z 1
µF/10V
CHD1AZ30F105
C1439
CHIP CERAMIC CAP.(1608) B K 0.01
µF/50V
CHD1JK30B103
C1441
CHIP CERAMIC CAP.(1608) F Z 0.1
µF/25V
CHD1EZ30F104
C1442
CHIP CERAMIC CAP.(1608) F Z 0.1
µF/25V
CHD1EZ30F104
C1443
CHIP CERAMIC CAP.(1608) F Z 0.1
µF/25V
CHD1EZ30F104
C1444
ELECTROLYTIC CAP. 22
µF/16V M H7
CE1CMAVSL220
C1445
CHIP CERAMIC CAP.(1608) B K 0.01
µF/50V
CHD1JK30B103
C1452
CHIP CERAMIC CAP.(1608) B K 0.01
µF/50V
CHD1JK30B103
C1463
CHIP CERAMIC CAP. CH J 820pF/25V
CHD1EJ3CH821
C1464
CHIP CERAMIC CAP.(1608) B K 2700pF/50V
CHD1JK30B272
C1465
ELECTROLYTIC CAP. 4.7
µF/50V M H7
CE1JMAVSL4R7
C1466
CHIP CERAMIC CAP.(1608) B K 0.01
µF/50V
CHD1JK30B103
C1468
ELECTROLYTIC CAP. 33
µF/16V M H7
CE1CMAVSL330
C1469
CHIP CERAMIC CAP.(1608) B K 0.01
µF/50V
CHD1JK30B103
C1604#
METALIZED FILM CAP. 0.22
µF/250V
CT2E224MS037
C1605#
METALIZED FILM CAP. 0.22
µF/250V
CT2E224MS037
C1606
CERAMIC CAP. F Z 0.01
µF/500V
CCD2JZP0F103
C1607
CERAMIC CAP. F Z 0.01
µF/500V
CCD2JZP0F103
C1610
ELECTROLYTIC CAP. 470
µF/200V LX
CA2D471S6017
C1611
CERAMIC CAP. BN 820pF/2KV
CCD3DKA0B821
C1612
FILM CAP.(P) 0.047
µF/50V J
CMA1JJS00473
C1613
FILM CAP.(P) 0.0018
µF/50V J
CMA1JJS00182
C1614
FILM CAP.(P) 0.1
µF/50V J
CMA1JJS00104
C1615
CERAMIC CAP. BN 680pF/2KV
CCD3DKA0B681
C1616
ELECTROLYTIC CAP. 100
µF/160V M
CE2CMZPDL101
C1617
ELECTROLYTIC CAP. 470
µF/35V M
CE1GMASDL471
C1618#
ELECTROLYTIC CAP. 1000
µF/16V M
CE1CMZPDL102
C1619
ELECTROLYTIC CAP. 220
µF/16V M
CE1CMASDL221
C1620
ELECTROLYTIC CAP. 1000
µF/16V M
CE1CMZPDL102
C1622
FILM CAP.(P) 0.0047
µF/50V J
CMA1JJS00472
C1625
ELECTROLYTIC CAP. 0.47
µF/50V M H7
CE1JMAVSLR47
C1626#
ELECTROLYTIC CAP. 10
µF/50V M
CE1JMASDL100
C1627
ELECTROLYTIC CAP. 1000
µF/16V M
CE1CMZPDL102
C1630#
SAFETY CAP. 4700pF/250V KX
CA2E472MR050
C1642
CHIP CERAMIC CAP.(1608) B K 1000pF/50V
CHD1JK30B102
C1643
ELECTROLYTIC CAP. 2200
µF/6.3V
CE0KMASDL222
C1661
ELECTROLYTIC CAP. 100
µF/16V M H7
CE1CMAVSL101
C1683
ELECTROLYTIC CAP. 220
µF/6.3V M H7
CE0KMAVSL221
C1688#
ELECTROLYTIC CAP. 470
µF/6.3V M
CE0KMASDL471
C1689
ELECTROLYTIC CAP. 47
µF/25V M
CE1EMASDL470
C1691
ELECTROLYTIC CAP. 470
µF/16V M
CE1CMASDL471
C1740
CHIP CERAMIC CAP.(1608) F Z 0.1
µF/25V
CHD1EZ30F104
C1747
ELECTROLYTIC CAP. 4.7
µF/50V M H7
CE1JMAVSL4R7
C1748
CHIP CERAMIC CAP.(1608) B K 0.022
µF/50V
CHD1JK30B223
C1752
CHIP CERAMIC CAP. F Z 1
µF/10V
CHD1AZ30F105
C1753
ELECTROLYTIC CAP. 10
µF/25V M H7
CE1EMAVSL100
C1754
CHIP CERAMIC CAP. F Z 1
µF/10V
CHD1AZ30F105
C1755
ELECTROLYTIC CAP. 22
µF/16V M H7
CE1CMAVSL220
C1756
ELECTROLYTIC CAP. 10
µF/25V M H7
CE1EMAVSL100
C1757
ELECTROLYTIC CAP. 4.7
µF/50V M H7
CE1JMAVSL4R7
C1758
CHIP CERAMIC CAP.(1608) B K 0.01
µF/50V
CHD1JK30B103
C1759
ELECTROLYTIC CAP. 22
µF/16V M H7
CE1CMAVSL220
C1760
CHIP CERAMIC CAP.(1608) B K 4700pF/50V
CHD1JK30B472
C1762
CHIP CERAMIC CAP.(1608) B K 0.01
µF/50V
CHD1JK30B103
C1763
CHIP CERAMIC CAP.(1608) B K 0.01
µF/50V
CHD1JK30B103
Ref. No.
Description
Part No.
C1764
ELECTROLYTIC CAP. 100
µF/10V M H7
CE1AMAVSL101
C1766
ELECTROLYTIC CAP. 2.2
µF/50V M H7
CE1JMAVSL2R2
C1769
ELECTROLYTIC CAP. 22
µF/16V M H7
CE1CMAVSL220
C1770
CHIP CERAMIC CAP.(1608) B K 4700pF/50V
CHD1JK30B472
C1771
CHIP CERAMIC CAP.(1608) B K 0.01
µF/50V
CHD1JK30B103
C1772
ELECTROLYTIC CAP. 4.7
µF/50V M H7
CE1JMAVSL4R7
C1773
ELECTROLYTIC CAP. 10
µF/25V M H7
CE1EMAVSL100
C1774
CHIP CERAMIC CAP. F Z 1
µF/10V
CHD1AZ30F105
C1775
CHIP CERAMIC CAP. F Z 1
µF/10V
CHD1AZ30F105
C1776
CHIP CERAMIC CAP. F Z 1
µF/10V
CHD1AZ30F105
C1777
CHIP CERAMIC CAP. F Z 1
µF/10V
CHD1AZ30F105
C1778
CHIP CERAMIC CAP.(1608) B K 0.01
µF/50V
CHD1JK30B103
C1779
ELECTROLYTIC CAP. 2.2
µF/50V M H7
CE1JMAVSL2R2
C1780
ELECTROLYTIC CAP. 4.7
µF/50V M H7
CE1JMAVSL4R7
C1781
CHIP CERAMIC CAP. F Z 1
µF/10V
CHD1AZ30F105
C1782
ELECTROLYTIC CAP. 4.7
µF/50V M H7
CE1JMAVSL4R7
C1783
CHIP CERAMIC CAP. F Z 1
µF/10V
CHD1AZ30F105
C1784
CHIP CERAMIC CAP.(1608) F Z 0.1
µF/50V
CHD1JZ30F104
C1786
ELECTROLYTIC CAP. 4.7
µF/50V M H7
CE1JMAVSL4R7
C1787
ELECTROLYTIC CAP. 22
µF/16V M H7
CE1CMAVSL220
C1788
ELECTROLYTIC CAP. 4.7
µF/50V M H7
CE1JMAVSL4R7
C1789
ELECTROLYTIC CAP. 22
µF/16V M H7
CE1CMAVSL220
C1790
ELECTROLYTIC CAP. 4.7
µF/50V M H7
CE1JMAVSL4R7
C1791
ELECTROLYTIC CAP. 4.7
µF/50V M H7
CE1JMAVSL4R7
C1792
ELECTROLYTIC CAP. 4.7
µF/50V M H7
CE1JMAVSL4R7
C1793
CHIP CERAMIC CAP. F Z 1
µF/10V
CHD1AZ30F105
C1794
ELECTROLYTIC CAP. 10
µF/25V M H7
CE1EMAVSL100
C1795
CHIP CERAMIC CAP. F Z 1
µF/10V
CHD1AZ30F105
C1796
CHIP CERAMIC CAP.(1608) B K 3300pF/50V
CHD1JK30B332
C1797
ELECTROLYTIC CAP. 100
µF/10V M H7
CE1AMAVSL101
C1801
ELECTROLYTIC CAP. 220
µF/16V M
CE1CMASDL221
C1807
ELECTROLYTIC CAP. 220
µF/16V M
CE1CMASDL221
C1810
CHIP CERAMIC CAP. B K 1500pF/50V
CHD1JK30B152
C1811
CHIP CERAMIC CAP. F Z 1
µF/10V
CHD1AZ30F105
C1812
CHIP CERAMIC CAP. B K 1500pF/50V
CHD1JK30B152
C1813
CHIP CERAMIC CAP. F Z 1
µF/10V
CHD1AZ30F105
C1814
ELECTROLYTIC CAP. 2.2
µF/50V M H7
CE1JMAVSL2R2
C1815
ELECTROLYTIC CAP. 47
µF/25V M H7
CE1EMAVSL470
C1816
CHIP CERAMIC CAP.(1608) CH J 100pF/50V
CHD1JJ3CH101
C1818
CHIP CERAMIC CAP. F Z 1
µF/10V
CHD1AZ30F105
C1819
CHIP CERAMIC CAP. F Z 1
µF/10V
CHD1AZ30F105
C1821
ELECTROLYTIC CAP. 470
µF/16V M
CE1CMASDL471
C1822
ELECTROLYTIC CAP. 470
µF/16V M
CE1CMASDL471
C1870
ELECTROLYTIC CAP. 47
µF/6.3V M H7
CE0KMAVSL470
C1871
ELECTROLYTIC CAP. 100
µF/16V M H7
CE1CMAVSL101
C1872
CERAMIC CAP. B K 470pF/100V
CCD2AKS0B471
C1873
FILM CAP.(P) 0.018
µF/100V J
CMA2AJS00183
CONNECTORS
CN601A
TERMINAL PRINTBORD PIN MS-PIN155155
JTEA001CHY01
CN601B
TERMINAL PRINTBORD PIN MS-PIN155155
JTEA001CHY01
CN1301
BOARD CONNECTOR 19P(PB FREE)
127301119K2
JCTWA19TG004
CN1602
BOARD CONNECTOR 19P(PB FREE)
127301119K2
JCTWA19TG004
CN1802
242 SERIES CONNECTOR 224202104W1
J322C04TG001
CN1803
TWG CONNECTOR 07P TWG-P07P-A1
J3TWA07TG001
DIODES
D1032
ZENER DIODE MTZJT-775.6B
QDTB0MTZJ5R6
D1204
LED LTL-4214M1
NPQZLTL4214M
D1211
ZENER DIODE MTZJT-776.2B
QDTB0MTZJ6R2
D1215
ZENER DIODE MTZJT-776.2B
QDTB0MTZJ6R2
D1216
LED LAMP 333GT/F45-50
NPWZ3GTF4550
D1217
LED LTL-4214M1
NPQZLTL4214M
Ref. No.
Description
Part No.
