Midland Radio SP-300 - Manual (Page 35)

MAXON
SP-300 HAND HELD
Page -32-
May 2001
REF # DESCRIPTION PART #
C128
CAP,TA,10UF,20%,16V,3216 102-023-1106
C129 CAP,ELE,10UF,16V20%3X5 5.0PT 081-032-3106
C131 CAP,CER,0.01UF,5%,50V,X7R,0603 100-521-1103
C132 CAP,TA,4.7UF,20V,3528:293D475X0020B2T20V 102-043-1475
C133 CAP,TA,1.0UF,20%,16V,3216 102-033-0105
C134 CAP, CER,.047UF,0603, 100-813-1473
C135 CAP, TA,10UF, 293D106X0004A2T4V 102-003-0106
C136 CAP, TA, 100UF, 20%, 6.3V, D 102-013-3107
C137 CAP, CER,470PF,10%,50V,X7R,0603 100-621-1471
C145 CAP, CER,470PF,10%,50V,X7R,0603 100-621-1471
C146 CAP, CER,220PF,5%,50V,COG,0603 100-520-1221
C901 CAP, CER, 0.01UF,5%,50V,X7R,0603 100-521-1103
C902 CAP, CER, 0.01UF,5%,50V,X7R,0603 100-521-1103
C903 CAP, CER, 0.01UF,5%,50V,X7R,0603 100-521-1103
C904 CAP, CER, 0.01UF,5%,50V,X7R,0603 100-521-1103
C905 CAP, CER,18PF,5%,50V,COG,0603 100-520-1180
C906 CAP, CER,18PF,5%,50V,COG,0603 100-520-1180
C907 CAP, CER, 0.1UF,5%,25V,X7R,0603 100-813-1104
C908 CAP,CER,33PF,5%,50V,COG,0603 100-520-1330
C910 CAP, CER, 0.01UF,5%,50V,X7R,0603 100-521-1103
C911 CAP, CER, 0.01UF,5%,50V,X7R,0603 100-521-1103
C999 CAP,CER,20PF,5%,50V,COG,0603 100-520-1200
CF1 FILTER CERAMIC LT-455FW 310-101-0010
CF2 FILTER, CER,CF455HT,455KHZ 310-101-0013
CON701 CONNECTOR SOCKET,SSW-106-02-G-D-RA 140-020-0054
D1 DIODE,SW,KDS181S,SOT-23 220-010-0004
D5 DIODE,PIN,UPP9401,NEEDPKG SIZE 220-020-0001
D6 DIODE,PIN,UPP9401,NEEDPKG SIZE 220-020-0001
D8 DIODE,SW,KDS193,SOT-23 220-010-0003
D9 DIODEVARICAPCHIP ND433G 5V (SOP-08) 220-040-0009
D11 DIODE,SW,KDS193,SOT-23 220-010-0003
D12 DIODE,SW,KDS193,SOT-23 220-010-0003
D13 DIODE,SW,KDS181S,SOT-23 220-010-0004
D14 DIODE,SW,KDS181S,SOT-23 220-010-0004
D15 DIODE, CHIP,SM4004,400V,1A,SMD 220-030-0003
D17 DIODE,SCHOTTKY,CHIP,PRLL5817,SOD87 220-040-0008
D18 DIODE,KDS160 220-010-0017
D20 DIODE,KDS160 220-010-0017
D901 DIODE,SW,KDS226,SOT-23 220-010-0005
D902 DIODE,SW,KDS226,SOT-23 220-010-0005
FUSE1 FUSE,60V,4A,25NM-040-L 700-020-0002
IC1 IC,VREG,TK11450M,+5V,SOT-23L,(R5) 441-010-0002
IC2 IC,PLL,MC145193FR2,SO-20,RS-440 440-050-0011
IC3 IC,OPAMP,LM358M,SO-8,DUALOPAMP 441-030-0006
IC5 IC,VHFRCVR,MC3371D,SO-16,NWRBAND 441-060-0007
IC6 IC,AUDIOAMP,LM386M-1,0.33W,SO-8 441-040-0002
L1 COIL,CHIP,47NH,20%,LL2012-F47NM 371-010-5470
L3 COIL,1.2UH:NL252018T-1R2J 371-004-31R2
L4 COIL,0.1UH:NL252018T-R10J 371-804-3R10
L5 COIL,0.1UH:NL252018T-R10J 371-804-3R10
L6 COIL,CHIP, 1.0UH:NL252018T-1R0J 371-017-3102
L7 COILSPRING 3X0.55X4T:LSMD 350-000-0104
L8 COILSPRING 3X0.55X4T:LSMD 350-000-0104
L11 COILSPRING 3X0.55X4T:LSMD 350-000-0104
L13 COILSPRING 2.8X0.4X8T:L 350-000-0106
L14 COILCHIP,0.68UH:NL252018T-R68J 371-313-3681
L15 COILCHIP,0.15UH:NL252018T-R15J 371-004-3R15
L16 COIL,CHIP, 1000U,300SS-102K=CP3 370-013-4102
REF # DESCRIPTION PART #
L17
COIL,CHIP, 1000U,300SS-102K=CP3 370-013-4102
L18 COIL,CHIP, 1.0UH:NL252018T-1R0J 371-017-3102
L19 COILCHIP,10UH:LER015T100K 371-005-3103
Q1 TRANS,BRT,PNP,KRA102SPB,SOT-23,SW,(PB) 870-010-0007
Q2 TRANS,BRT,PNP,KRA110SPK,SOT-23,SW,PK 870-010-0010
Q3 TRANS,BRT,PNP,KRA110SPK,SOT-23,SW,PK 870-010-0010
Q4 TRANS,BRT,PNP,KRA110SPK,SOT-23,SW,PK 870-010-0010
Q5 TRANS,KRA104S,SOT-23 870-010-0005
Q6 TRANS,NPN,KTC3875(BL),SOT-23,SW,(ALL) 870-200-0006
Q7 TRANS,PNP,KTA1504(Y),SOT-23,SW 870-100-0004
Q8 TRANS,PNP,KTA1504(Y),SOT-23,SW 870-100-0004
Q11 TRANS,NPN,KTC3875(BL),SOT-23,SW,(ALL) 870-200-0006
Q12 TRANS,NPN,BFR92A,SOT-23,RFAMP,(P2P) 870-200-0020
Q13 TRANS,NPN,KTC3875(BL),SOT-23,SW,(ALL) 870-200-0006
Q14 TRANS,NPN,KTC3875(BL),SOT-23,SW,(ALL) 870-200-0006
Q16 TRANS,900MHZ AMP,MMB1321Q4LT1,SOT-23 870-200-0008
Q17 TRANS,900MHZ AMP,MMB1321Q4LT1,SOT-23 870-200-0008
Q18 TRANS,BRT,NPN,KRC104S,SOT-23,SW,ND 870-020-0001
Q19 TRANS,NPN,KTC3875(BL),SOT-23,SW,(ALL) 870-200-0006
Q21 TRANS,NPN,KTC3875(BL),SOT-23,SW,(ALL) 870-200-0006
Q22 TRANS,PNP,KTA1663(Y),SOT-89,HC/SW,(HY) 870-150-0002
Q23 TRANS,BRT,NPN,KRC104S,SOT-23,SW,ND 870-020-0001
Q24 TRANS,BRT,NPN,KRC104S,SOT-23,SW,ND 870-020-0001
Q25 TRANS,NPN,BFR92A,SOT-23,RFAMP,(P2P) 870-200-0020
Q26 TRANS,NPN,KTC3875(BL),SOT-23,SW,(ALL) 870-200-0006
Q27 TRANS,NPN,KTC3875(BL),SOT-23,SW,(ALL) 870-200-0006
Q28 TRANS,BRT,NPN,KRC104S,SOT-23,SW,ND 870-020-0001
Q31 TRANS,BRT,NPN,KRC104S,SOT-23,SW,ND 870-020-0001
Q32 TRANS,BRT,NPN,KRC104S,SOT-23,SW,ND 870-020-0001
Q33 TRANS,PNP,KTA1504(Y),SOT-23,SW 870-100-0004
Q34 TRANS,BRT,NPN,KRC104S,SOT-23,SW,ND 870-020-0001
Q901 TRANS,NPN,KTC4075,UMT3 870-200-0031
Q902 TRANS,KTA2014,MAX-900K 870-100-0018
Q903 TRANS,NPN,KTC4075,UMT3 870-200-0031
Q904 TRANS,NPN,KTC4075,UMT3 870-200-0031
Q905 TRANS,NPN,KTC4075,UMT3 870-200-0031
R1 RES,TF,10K,5%,1/16W, +/-200,0603 741-102-1103
R2 RES,TF,100K,5%,1/16W,+/-200,0603 741-102-1104
R3 RES,TF,2.2K,5%,1/16W,TC250,0603 741-102-1222
R4 RES,1.8K,1/16W,5%,T 1608 741-102-1182
R5 RES,1.8K,1/16W,5%,T 1608 741-102-1182
R6 RES,TF,2K, 1/16W,5%,T 1608 741-102-1202
R7 RES,1.8K,1/16W,5%,T 1608 741-102-1182
R8 RES,910,1/10W,5%,T 2012 741-117-2911
R11 RES,TF,100, 5%,1/16W, +/-200,0603 741-102-1101
R12 RES,TF,5.6K,5%,1/16W,T1608 741-102-1562
R13 RES,TF,2.7K,5%,1/16W,+/-200,0603 741-102-1272
R14 RES,TF,2.7K,5%,1/16W,+/-200,0603 741-102-1272
R15 RES,TF,100, 5%,1/16W, +/-200,0603 741-102-1101
R16 RES,910,1/10W,5%,T 2012 741-117-2911
R17 RES,TF,12K,5%,1/16W, +/-200,0603 741-102-1123
R21 RES,TF,100, 5%,1/16W, +/-200,0603 741-102-1101
R22 RES,TF,4.7K,5%,1/16W,+/-200,0603 741-102-1472
R23 RES,120 1/16W5%T 1608 741-102-1121
R24 RES,5.6K,1/16W,5%,T 1608 741-102-1562
R25 RES,TF,3.3K,5%,1/16W,+/-200,0603 741-102-1332
R26 RES,TF,18,1/16W, 5%,T 1608 741-102-1180
R27 RES,TF,4.7K,5%,1/16W,+/-200,0603 741-102-1472
R28 RES,56,1/16W, 5%,T 1608 741-102-1560
R35 RES,8.2K,1/16W,5%,T 1608 741-102-1822
