Midland Radio SP-300 - Manual (Page 32)

MAXON
SP-300 HAND HELD
Page -29-
May 2001
SP-300 SERIES UHF & VHF DIGITAL SECTION PARTS LIST
REF# DESCRIPTION PART#
DIGITAL SECTION VHF& UHF (COMMON PARTS)
PTT SWITCH BOARD (SEE NOTE1)
650-180-0017
FUSE BOARD ASSY 650-200-0004
C136 CAP,TA,100UF 293D107X0006E2T6V 102-013-3107
C400 CAP,CER,0.0068UF,50V,5%,X7R,1/16W,0603 100-521-1682
C404 CAP,CER,.047UF,0603, 100-813-1473
C405 CAP,CER,0.001UF,10%,50V,X7R,0603 100-621-1102
C406 CAP,CER,0.1UF,+80-20%,25V,Y5V,0603 100-813-1104
C413 CAP,CER,470PF,10%,50V,X7R,0603 100-621-1471
C414 CAP,CER,470PF,10%,50V,X7R,0603 100-621-1471
C415 CAP,CER,470PF,10%,50V,X7R,0603 100-621-1471
C416 CAP,CER,470PF,10%,50V,X7R,0603 100-621-1471
C417 CAP,CER,220PF,5%,50V,COG,0603 100-520-1221
C418 CAP,CER,220PF,5%,50V,COG,0603 100-520-1221
C419 CAP,CER,220PF,5%,50V,COG,0603 100-520-1221
C420 CAP,CER,220PF,5%,50V,COG,0603 100-520-1221
C421 CAP,CER,220PF,5%,50V,COG,0603 100-520-1221
C422 CAP,CER,0.01UF,5%,50V,X7R,0603 100-521-1103
C423 CAP,TA,10UF,293D106X06R3A2T6.3V 102-013-0106
C424 CAP,CER,470PF,10%,50V,X7R,0603 100-621-1471
C425 CAP,CER,470PF,10%,50V,X7R,0603 100-621-1471
C426 CAP,CER,470PF,10%,50V,X7R,0603 100-621-1471
C427 CAP,CER,0.001UF,10%,50V,X7R,0603 100-621-1102
C428 CAP,CER,470PF,10%,50V,X7R,0603 100-621-1471
C429 CAP,CER,470PF,10%,50V,X7R,0603 100-621-1471
C430 CAP,CER,0.1UF,+80-20%,25V,Y5V,0603 100-813-1104
C431 CAP,TA,4.7UF,20%,10V,3216 102-023-0475
C432 CAP,CER,470PF,10%,50V,X7R,0603 100-621-1471
C433 CAP,CER,470PF,10%,50V,X7R,0603 100-621-1471
C434 CAP,CER,0.1UF,+80-20%,25V,Y5V,0603 100-813-1104
C435 CAP,CER,0.1UF,10%,50V,X7R,0603 100-621-1104
C436 CAP,CER,0.022UF,10%,50V,X7R,0603 100-621-1223
C437 CAP,CER,1UF,+80-20%,16V,Y5V,0805 100-803-2105
C438 CAP,CER,470PF,10%,50V,X7R,0603 100-621-1471
C439 CAP,CER,470PF,10%,50V,X7R,0603 100-621-1471
C441 CAP,CER,0.0018UF,50V,10%,X7R,1/16W,0603 100-621-1181
C442 CAP,CER,0.022UF,10%,50V,X7R,0603 100-621-1223
C443 CAP,CER,0.0047UF,10%,50V,X7R,0603 100-621-1472
C444 CAP,CER,0.01UF,5%,50V,X7R,0603 100-521-1103
C446 CAP,CER,47PF,5%,50V,COG,0603 100-520-1470
C448 CAP,CER,47PF,5%,50V,COG,0603 100-520-1470
C449 CAP,CER,0.033UF,10%,16V,X7R,0603 100-601-1333
C452 CAP,CER,0.1UF,10%,25V,X7R,0805 100-611-2104
C453 CAP,CER,0.0033UF,50V,10%,X7R,1/16W,0603 100-621-1332
C454 CAP,CER,.68UF,+/-20%,50V,Y5V,0805 100-723-2684
C455 CAP,CER,.082UF,10%,50V,X7R,0805 100-621-2823
C456 CAP,CER,120PF,0603,5%,50V 100-520-1121
C458 CAP,CER,0.1UF,10%,25V,X7R,0805 100-611-2104
C459 CAP,CER,0.1UF,+80-20%,25V,Y5V,0603 100-813-1104
C460 CAP,CER,15PF,5%,50V,COG,0603 100-520-1150
C461 CAP,CER,15PF,5%,50V,COG,0603 100-520-1150
C462 CAP,CER,.047UF,+80-20%,50V,Y5V,0805 100-823-2473
C463 CAP,CER,.047UF,+80-20%,50V,Y5V,0805 100-823-2473
NOTES:
1. Components are not available,assembly is non-repairable.
REF# DESCRIPTION PART#
C464
CAP,CER,.033UF,10%,50V,0805 100-623-2333
C465 CAP,CER,.033UF,10%,50V,0805 100-623-2333
C466 CAP,CER,.033UF,10%,50V,0805 100-623-2333
C467 CAP,CER,.033UF,10%,50V,0805 100-623-2333
C468 CAP,CER,.033UF,10%,50V,0805 100-623-2333
C469 CAP,CER,.047UF,+80-20%,50V,Y5V,0805 100-823-2473
C470 CAP,CER,1UF,+80-20%,16V,Y5V,0805 100-803-2105
C471 CAP,CER,0.1UF,+80-20%,25V,Y5V,0603 100-813-1104
C472 CAP,CER,0.001UF,10%,50V,X7R,0603 100-621-1102
C474 CAP,CER,1UF,+80-20%,16V,Y5V,0805 100-803-2105
C476 CAP,CER,0.1UF,+80-20%,25V,Y5V,0603 100-813-1104
C477 CAP,CER,470PF,10%,50V,X7R,0603 100-621-1471
C478 CAP,TA,10UF,293D106X0004A2T4V 102-003-0106
C479 CAP,CER,470PF,10%,50V,X7R,0603 100-621-1471
C480 CAP,CER,470PF,10%,50V,X7R,0603 100-621-1471
C481 CAP,CER,470PF,10%,50V,X7R,0603 100-621-1471
C482 CAP,CER,470PF,10%,50V,X7R,0603 100-621-1471
C483 CAP,CER,470PF,10%,50V,X7R,0603 100-621-1471
C484 CAP,CER,470PF,10%,50V,X7R,0603 100-621-1471
C485 CAP,CER,470PF,10%,50V,X7R,0603 100-621-1471
C701 CAP,TA,10UF,293D107X0006E2T6V 102-013-3107
CH404 SW,ROTARY,EC10RP04-66(4Channel) 830-010-0010
CH404 SW,ROTARY,EC10RP04-66(16Channel) 830-010-0011
CON401 CONN, SMTSTRIPS,MMT-104-01-T-SH-P-TR 140-030-0062
CON404 SKT,14P/SIP,STR,LP,52231-1417 140-020-0032
CON406 PIN,HDR,4P/SIP,R ANG,SHROUD,WAF, 140-030-0043
CON701 CONNECTOR SOCKET SSW-106-02-G-D-RA 140-020-0054
D401 DIODE,SW,KDS181S,SOT-23 220-010-0004
D402 DIODE,SW,KDS181S,SOT-23 220-010-0004
D403 DIODE,SW,KDS193,SOT-23 220-010-0003
D404 DIODE,SW,KDS184S,SOT-23 220-010-0002
D405 DIODE,ZNR,5.6V,SOT-23,0.225W,MMBZ5232 221-010-0056
D406 DIODE,ZNR,5.6V,SOT-23,0.225W,MMBZ5232 221-010-0056
D407 DIODE,ZNR,5.6V,SOT-23,0.225W,MMBZ5232 221-010-0056
D701 DIODE,ZNR,5.6V,SOT-23,0.225W,MMBZ5232 221-010-0056
IC401 IC,SW/MUX,MC14066BDR2,SO-14,A-SW 444-050-0001
IC402 IC,SW/MUX,MC14066BDR2,SO-14,A-SW 444-050-0001
IC404 IC,OPAMP,KIA324F,SO-14,QUAD 441-030-0002
IC405 IC,OPAMP,LM358M,SO-8,DUALOPAMP 441-030-0006
IC406 IC,OPAMP,KIA324F,SO-14,QUAD 441-030-0002
IC407 IC,FILTER,BLP,MF6CWM-100,SO-14 441-090-0001
IC408 IC,EEPROM,AT93C56-10SI,SO-08,2K,VCC2-5V 442-010-0003
IC409 IC,CPU,OTP,HD4074818H,FP-80A,4BIT 443-103-0001
IC410 IC,OPAMP,KIA324F,SO-14,QUAD 441-030-0002
IC411 IC,A-MUX/DEMUX,MC14053BD,SO-16,3PDT 440-060-0001
L410 COILCHIP,10UH:LER015T100K 371-005-3103
LED1 LEDCHIP,SML-020MLTT86SMD 240-030-0035
Q401 TRANS,BRT,PNP,KRA110SPK,SOT-23,SW,PK 870-010-0010
Q403 TRANS,BRT,NPN,KRC104S,SOT-23,SW,ND 870-020-0001
Q404 TRANS,BRT,NPN,KRC104S,SOT-23,SW,ND 870-020-0001
Q405 TRANS,BRT,NPN,KRC104S,SOT-23,SW,ND 870-020-0001
Q406 TRANS,PNP,BRT,KRA101S,SOT-23,SW,PA 870-010-0002
Q407 TRANS,NPN,KRC101S,BRT,SOT-23 870-020-0002
Q410 TRANS,KRA104S,SOT-23 870-010-0005
Q411 TRANS,BRT,NPN,KRC104S,SOT-23,SW,ND 870-020-0001
Q412 TRANS,KRA104S,SOT-23 870-010-0005
