MODEL: WD-52525 / WD-52725 / WD-52825 / WD-62525 / WD-62725 / WD-62825
Ma in Matrix (MMTX)
Ite m # Abbre v. Description
Da ta
Ra nge
Initia l
Data
1 TNTM Hue Control 0~63 31
4 COLM Color Gain Control 0~63 19
15 YDRM Y Drive Gain Control 0~31 5
19 VPDM V Signal Pedestal Control 0~15 2
20 UPDM U Signal Pedestal Control 0~15 2
Sub Ma trix (SMTX)
Ite m # Abbre v. Description
Da ta
Ra nge
Initia l
Data
1 TNTS Hue Control 0~63 31
4 COLS Color Gain Control 0~63 16
15 YDRS Y Drive Gain Control 0~31 5
19 VPDS V Signal Pedestal Control 0~15 2
20 UPDS U Signal Pedestal Control 0~15 2
Light Engine (light e ng)
Item # Abbrev. Description
120 GGH Temp. H Green Gain
121 GRH Temp. H Red Gain
122 GBH Temp. H Blue Gain
123 GGM Temp. M Green Gain
124 GRM Temp. M Red Gain
125 GBM Temp. M Blue Gain
126 GGL Temp. L Green Gain
127 GRL Temp. L Red Gain
128 GBL Temp. L Blue Gain
SERVICE MODE - Adjustment Items and Initial Data Values
AD9883A
Item # Abbrev. Description
Data
Range
12 ROFF Red Offset 0~127
14 BOFF Blue Offset 0~127
Format (fmt)
Item # Abbrev. Description
Data
Range
1 HPOS Horizontal Position 0~255
2 VPOS Vertical Position *0~255
* Do Not set VPOS Data to 0 or 255 and press Enter.
longer be visible.)
(Video will be muted and On Screen Menus will no
