25
Adjustment of minimum level
Oven burner
• Remove the top pan support as well as
the burner caps and the burner crowns.
• Unscrew and remove the 4 top plate
fixing screws and remove the top plate.
• Light the burner knob on position 9 and
leave the oven door closed for about 10
min.
• Turn the knob slowly to position 1.
• Pull off the knob to adjust minimum flow.
• Unscrew or screw the by-pass screw (is
it above of tap shaft) until a regular small
flame is reached.
• For LPG, adjust the by-pass screw for
minimum flame setting.
The flame shouldn’t extinguish when closing
the oven door.
Grill burner
The grill temperature cannot be adjusted.
To obtain a lower temperature or slower
cooking time the grill pan must be lowered
away fron the flame.
AFTER COMPLETION OF ANY
REPAIRS, ADJUSTMENTS OR
CONVERSION THE STATUTORY SAFETY
TESTS MUST BE CARRIED OUT.
