INSTRUCTIONS FOR THE INSTALLER
SAFETY ADVICE
• Before installation ensure that the local
distribution conditions (gas type and
pressure) and the pre-setting of the
appliance are consistent.
• This appliance must be installed only in
a room with good ventilation.
• This appliance must not connected to a
flu. It has to be installed and connected
in accordance with the rules in force.
Special attention should be paid to the
applicable disposal concerning
ventilation.
• The adjacent furniture panels have to
be heat proof or protected by such
material.
• The adjusting conditions of this
appliance are mentioned on the rating
plate.
Connection to gas supply.
Check that the gas flow and the diameter of
the supply pipe is sufficient to supply all the
appliances of the installation.
•
Check that all connections are tight.
• Install an accessible and visible gas
tap to isolate the appliance.
- Installation of flues and ventilation
for gas appliances of rated input not
exceeding 60 kW (1
st , 2 nd and 3 rd
family gases) – Part 2 Specification
for installation of ventilation for gas
appliances – BS 5440;
- Gas burning appliances – Part 3
Domestic cooking appliances
burning gas – BS 5386;
- Specification for installation of low
pressure gas pipe work of up to
20mm (R1) in domestic premises (2
nd
family gas) – BS 6891;
- Pipe threads for tubes and fittings
where pressure-tight joints are made
on the threads (metric dimensions) –
BS 21: 1985;
- Flexible hoses, end fittings and
sockets for gas burning appliances –
BS 669;
Installation of domestic gas cooking
appliances (1
st , 2 nd and 3 rd family gases)
– BS 6172: 1990;
TECHNICAL DATA
Table no.1
(Cat : II
2H3+
)
Cons
Burner
Normal
power
(kW)
Economic
power
(kW)
By-
pass
(mm)
Gas Type
Pressure
(mbar)
Nozzle
diameter
(mm) m 3 /h g/h
RAPID 2.60 0.72 0.42
Natural Gas
Butane
Propane 20 mbar
28-30mbar
37mbar
1.12
0,86
0,86 0.248
188,8
SEMI-
RAPID
2.00 0.43 0.32
Natural Gas
Butane
Propane 20 mbar
28-30mbar
37mbar
0.96
0,71
0,71 0.191
145,2
AUXILIARY 1.00 0.35 0.29
Natural Gas
Butane
Propane 20 mbar
28-30mbar
37mbar
0.70
0,50
0,50 0.093
72,6
OVEN 3.20 1.00 0.46
Natural Gas
Butane
Propane 20 mbar
28-30mbar
37mbar
1.30
0,88
0,88 0.305
232,4
GRILL 1.80 - -
Natural Gas
Butane
Propane 20 mbar
28-30mbar
37mbar
1.00
0,67
0,67 0.172
130,7
