Changing the small burner orifice
d Small burner orifice
e Air sleeve
f Air vent
^ First, loosen fitting, c, using an 8 mm
wrench. Hold nut,
b, with a 12 mm
wrench while doing this to prevent
the tubing from twisting.
^ Then remove fitting, b, from fitting,
a, by using two 12 mm wrenches.
^ Remove the orifice, d, and replace it
with the new orifice.
^ Rotate the air sleeve, e, until there is
a
1
/
16
" (2 mm) gap between the
sleeve and the air vent,
f, as shown.
^ Reassemble the burners and test the
unit for leaks. It can be operated
without the upper cover in place by
igniting the flames with a match.
Converting to LP gas
21
(2mm)
g f
b c d
e f g
1/16"
