Meters and Gauges
(Black-out meter)
When the ignition switch is in the ON position, the dashboard gauges illuminate.
Speedometer ...................................................................................................... page 5-32
Odometer, Trip Meter and Trip Meter Selector .................................................. page 5-32
Tachometer ........................................................................................................ page 5-33
Engine Coolant Temperature Gauge .................................................................. page 5-33
Fuel Gauge ........................................................................................................ page 5-34
