2.8
Connection of Battery Module EXB
1.
Check that the battery circuit breaker (5)
is OFF (“0”) position.
2.
Connect the battery power cable
to the connectors
and
of the Power and Battery
Modules.
3.
Connect the battery detection cable
between connectors
and
of the Power and Battery
Modules.
Figure 2-16: Rear view of Battery Module cable connections.
12
4
42
13
6
40
14
EX 5/7/11RT Systems
Installation
2 — 18
86-86000-00 B00
4
42
40
13
14
6
12
