Table 1-5: Battery Module Ratings.
1.2 Standard Configuration
The EX 5/7/11RT systems can be set up in tower or rack configurations.
1.2.1 Tower Configuration
Figure 1-1: Tower Configuration with Power Module, Battery Module, and optional Transformer Module.
EX 5/7/11RT Systems
Introduction 1 — 4 86-86000-00 B00
Part Number 86207 86209
Battery Type 12VDC/7Ah 12VDC/9Ah
Battery Output Voltage 240VDC 240VDC
www .mge ups. com
www .mge ups. com
OFF
ON
BATTERY MODULE
POWER MODULE
EX 11 RT
EXB RT
EX RT T ransfo rmer
TRANSFORMER MODULE
