7. SYSTEM SETUP
MAIN SETUP PAGE
1. HDD INFORMATION
2. DATE-TIME SETUP
3. DISPLAY SETUP
4. CAMERA SETUP
5. BUZZER SETUP
6. RELAY SETUP
7. SYSTEM SETUP
8. ADVANCED SETUP
MENU, ESC: EXIT, ENTER: RUN
SYSTEM SETUP
1. DWELL INTERVAL
2. LANGUAGE
3. VIDEO INPUT
4. RS-485 ID
5. RS-485 PROTOCOL
6. RS-485 BAUD RATE
UPTIME: xx HRS
MENU, ESC: EXIT: : MODIFY
SYSTEM SETUP
1. DWELL INTERVAL:
- 0 ~ 999SEC
2. LANGUAGE:
-
ENGLISH / CHINESE / JAPANESE / FRENCH
-
After change language, user needs to exit menu. Language would change next time back to menu.
3. VIDEO INPUT: NTSC / PAL system detection.
- AUTO / NTSC / PAL
- User needs to connect camera with power first before DVR power on if choose AUTO. If manual
NTSC / PAL, then need to power reset.
4. RS-485 ID:
- 01 ~ 16
5. RS-485 PROTOCOL
- KEYB / LILIN / PELCO-P / PELCO-D / NICECAM / OFF
6. RS-485 BAUD RATE
- 1200 / 2400 / 4800 / 9600
-UPTIME: xx HRS. This means the total system working time after DVR first power on.
RS-485 ID and protocol is the command for system control keyboard. If user has no keyboard to
control then does not have to care.
Press direction buttons up/down to choose items.
Press values change button to change values.
