UHF
XPR ™ 8300
MOTOTRBO ™ Repeater Specifi cations
General Specifi cations
UHF – XPR 8300
Channel Capacity 1
Technical RF Output 25-40 W
Frequency 403-470 MHz
Dimensions (HxWxL) 5.22 x 19 x 11.67 in (132.6 x 482.6 x 296.5 mm)
Weight 31 lbs (14 kg)
Voltage Requirements 100-240 V AC (13.6 V DC)
Current Drain: Standby 1 A (1 A DC typical)
Transmit 3.8 A (11 A DC typical)
Operating Temperature Range -30°C to +60°C
Max Duty Cycle 100%
FCC Description ABZ99FT4025
IC Description 109AB-99FT4025
Receiver
UHF – XPR 8300
Frequencies 403-470 MHz
Channel Spacing 12.5 kHz / 25 kHz
Frequency Stability (-30° C, +60° C, +25° C) +/- 0.5 ppm
Analog Sensitivity (12 dB SINAD) 0.30 uV
0.22 uV (typical)
Digital Sensitivity 5% BER: 0.3 uV
Intermodulation (TIA603C) 75 dB
Adjacent Channel Selectivity
TIA603
TIA603C
65 dB @ 12.5 kHz, 75 dB @ 25 kHz
50 dB @ 12.5 kHz, 75 dB @ 25 kHz
Spurious Rejection 75 dB
Audio Distortion @ Rated Audio 3% (typical)
Hum and Noise -40 dB @ 12.5 kHz
-45 dB @ 25 kHz
Audio Response TIA603C
Conducted Spurious Emission -57 dBm
Transmitter
UHF – XPR 8300
Frequencies 403-470 MHz
Channel Spacing 12.5 kHz / 25 kHz
Frequency Stability (-30° C, +60° C, +25° C) +/- 0.5 ppm
Power Output 25-40 W
Modulation Limiting +/- 2.5 kHz @ 12.5 kHz
+/- 5.0 kHz @ 25 kHz
FM Hum and Noise -40 dB @ 12.5 kHz
-45 dB @ 25 kHz
Conducted / Radiated Emission -36 dBm < 1 GHz
-30 dBm > 1 GHz
Adjacent Channel Power (TIA603C) 60 dB @ 12.5 kHz
70 dB @ 25 kHz
Audio Response TIA603C
Audio Distortion 3%
FM Modulation 12.5 kHz: 11K0F3E
25 kHz: 16K0F3E
4FSK Digital Modulation 12.5 kHz Data Only: 7K60FXD
12.5 kHz Data & Voice: 7K60FXE
Digital Vocoder Type AMBE++
Digital Protocol ETSI-TS102 361-1
Specifi cations subject to change without notice. All specifi cations shown are typical. Radio meets applicable regulatory requirements. Version 4 03/07
