Mobile Radio
Part Number Description Benefi ts
Audio
RMN5052 Compact Microphone Standard microphone for MOTOTRBO.
RMN5065 Keypad Microphone IMPRES The Enhanced Keypad Microphone allows the user to navigate radio menus from the microphone.
RMN5053 Heavy Duty Microphone IMPRES For users who want a more durable microphone; also ideal for those who need a larger microphone that is easy to handle when operating
while wearing gloves.
RMN5054 Visor Microphone IMPRES Visor mic for use with external PTT accessories; mic mounts to vehicle’s visor for hands-free radio operation.
RMN5050 Desktop Microphone Intended to be used for a mobile radio that is being used in a desktop confi guration.
Loudspeakers
RSN4002 13 Watt External Speaker External speakers ideal for extremely noisy environments.
RSN4003 7.5 Watt External Speaker
RSN4004 5 Watt External Speaker
Desktop
RSN4005 Desktop Tray with Speaker A desktop tray that includes a speaker for increased volume when receiving calls in high-noise areas.
GLN7318 Desktop Tray without Speaker Ideal for securing the mobile radio in place in a desktop confi guration.
HPN4007 Power Supply and Cable (25 - 60 Watt Models) Provides power when using a mobile from a desktop.
HPN4008 Power Supply and Cable (1 - 25 Watt Models)
GPN6145 Switchmode Power Supply (1 - 25 Watt Models) Has a provision for a back up battery hook up.
GKN6266 Power Supply Cable Power cable for GPN6145 switchmode power supply.
HKN9088 Mobile Mini U Antenna Adapter - 8 ft Cable
PMLN5072 Hardware Kit for Rear Accessory Connector
Mounting
RLN6077 Low Profi le Trunnion Kit
RLN6078 High Profi le Trunnion Kit
RLN6079 Key Lock Trunnion Kit Key lock mount bracket allows the mobile to be mounted and locked giving radio users extra protection from theft by requiring the use of a
key to lock/unlock the radio from its position in the mounting bracket.
RLN5933 In Dash (DIN) Mounting Kit
Cables
RKN4136 Ignition Sense Cable
HKN4137 Power Cable to Battery - 10 ft, 15 amp
HKN4192 Power Cable to Battery - 20 ft, 20 amp
PMKN4018 Mobile Rear Accessory Connector Universal Cable
Antennas
The following antennas combine UHF and GPS capability.
PMAE4030 Combination GPS / UHF 403-430 MHz, 1/4 Wave Roof Mount Antenna Combination GPS/Mobile antenna design with Mini U connector provides GPS tracking coverage and voice/data wireless coverage
capabilities for fl eet monitoring or fl eet tracking applications.
PMAE4032 Combination GPS / UHF 406-420 MHz, 3.5 dB Gain Roof Mount Antenna
PMAE4031 Combination GPS / UHF 450-470 MHz, 1/4 Wave Roof Mount Antenna
PMAE4033 Combination GPS / UHF 450-470 MHz, 3.5 dB Gain Roof Mount Antenna
PMAE4034 Combination GPS / UHF 450-470 MHz, 5 dB Gain Roof Mount Antenna
The following antennas are intended for customers who have existing mobile antennas and need to add GPS capability.
PMAN4000 Fixed Mount GPS Active Antenna This discreet stand-alone GPS antenna has a semi-permanent mount easily assembled with minimal tools to a roof or trunk of a vehicle.
PMAN4002 Magnetic Mount GPS Active Antenna This discreet stand-alone GPS antenna can be mounted either magnetically, via screw or via tape on the roof or trunk of a vehicle.
The following antennas are intended for customers who do not plan to use the GPS capability of the radio.
HAE4002 UHF 403-430 MHz, 1/ 4 Wave Roof Mount Antenna The signals for these antennas are radiated vertically, making them ideal for urban environments where buildings might obstruct the signal.
HAE4003 UHF 450-470 MHz, 1/ 4 Wave Roof Mount Antenna
HAE4010 UHF 406-420 MHz, 3.5dB Gain Roof Mount Antenna These antennas are designed to direct the signal more towards the horizon, making them ideal for applications in more geographically fl at
regions where signal coverage is sparse and must cover a larger area.
HAE4011 UHF 450-470 MHz, 3.5dB Gain Roof Mount Antenna
RAE4004 UHF 450-470 MHz, 5dB Gain Roof Mount Antenna
Miscellaneous
RLN5926 Push Button PTT Push button with push-to-talk feature provides hands-free operation of a radio in a vehicle, allowing the user to transmit messages without
using a mobile microphone. Push-to-talk button can be held in the hands or mounted in the vehicle with touch fasteners.
RLN5929 Emergency Footswitch Emergency footswitch enables the user to notify the base station quickly and discreetly that he or she is in an emergency situation.
Pressing the footswitch sends a signal to the base station and activates the microphone to allow communication with the base station.
HLN9073 Microphone Hang Up Clip (all microphones)
HLN9414 Universal Microphone Hang Up Clip (all microphones)
HKN9557 PL259 / Mini-U Antenna Adapter - 8' cable
Part Number Description Benefi ts
Duplexers
HFE8400 UHF Untuned Duplexer, 406-450MHz Allows the use of just one antenna that both transmits and receives.
RFE4000 UHF Untuned Duplexer, 450-470MHz
Antennas
RDE4556 UHF 3.8dB Gain Antenna
Mounting
PMLE4476 Wall Mount Kit for XPR 8300 Includes brackets and screws to easily mount XPR 8300 to the wall.
Preselector
HFE8459 UHF Preselector, 440-474MHz Provides additional isolation for the receiver in RF dense sites.
Lightening Protection
RRX4025 Lightening Arrestor Provides lightning and grounding protection to the repeaters.
RRX4032 Tower Mounting Hardware
RRX4038 Surge Suppressor
Repeater
13
