Customising 518 using Config
27
518 User Guide
The gain of 518 can either be displayed in absolute dB in the range -99dB
to +12dB, or as a Meridian volume number 0 to 99 – where 87
corresponds to 0dB.
2. Use the and , Volume keys to choose dB or ##.
Setting up sources
For each of the twelve source selection keys on the Remote control you
choose a display Logo and a physical input connection.
Normally as shown, we set the CD key to give a CD display with the D1
(Digital 1) input selected. You may however wish to display CD1 for your
main CD player and to connect it to D2.
A full list of possible logos and their meanings is:
Source
Logo
Source
Logo
Source
Logo
CD
CD
S-VHS
SV
DAB
DAB
Radio
RD
Betamax
β
m
Dig. Sat
DSat
LP
LP
Camera
Ca
ADC
ADC
Tape 1
T1
Video 8
V8
R-Reel
Reel
Tape 2
T2
CD-V
CD-V
FM tuner
FMTun
CDR
Cr
CD-I
CD-I
AM tuner
AMTun
Cable
Cb
CD-T
CD-T
MW tuner
MWRad
Teletext
TX
CD Photo
CD Photo
SW tuner
SWRad
VCR 1
V1
CD Lib
CD Li
LW tuner
LWRad
VCR 2
V2
CD Jbox
CD Jbox
Line
Line
Laserdisc
LD
CD-ROM
CD-ROM
Mic.
Mic
Satellite
SA
DAT
DAT
Aux
Aux
CDX
C2
DCC
DCC
Mixer
Mixer
78 rpm
78 rpm
Phono
Phono
Simul.
Simul
VHS
VH
Minidisc
Mdisc
Computer
PC
Choosing source logos
Note at any time in the source configuring process you can use the front-
panel Display key or the handset Mute key to return to the root menu
with a display like ‘Auto'.
In Config mode:
1. Press Source until you see a Remote-key (source) + logo display like
2. Press Source until the Remote key name for the source you wish to
configure is displayed.
Vol.
dB
CD
CD
