21

SPECIFICATIONS

Specifications are nominal and subject to change.


GENERAL

Frequency Range

(162.40, 162.425, 162.45, 162.475, 162.50,

162.525, 162.55MHz)

Number of WX Channels

…………….7

Input Voltage .........................................3 Volts DC

Dimensions …..

73mm

W x 105mm H x 30mm D

(2

7

/

8

x 4

1

/

8

x 1

1

/

4

in.)

Battery life (alkaline): 6 to12 days monitoring, up to 6 months in

clock mode.

Battery life (Ni-cad): 2 to 4 days monitoring, up to 2 months in

clock mode.


RECEIVER

20 dB Quieting Sensitivity…………...…..0.5 uV

FIPS Code Sensitivity @5kHz Dev..…….0.5uV

Channel Selectivity ………..................±25kHz, 30dB

Speaker Impedance ……………......…..4 ohms

Power Output @10%THD........................150 mW max.
