AC output ratings
Voltage:
480 VAC ± 0.5% (steady-state conditions)
480 VAC ± 5% (transient conditions
from 0% to 100% or 100% to 0%)
Frequency:
60 Hz ± 0.1% (free-running)
Phases:
3 Ø (phase sequence must be A, B, C)
Wires:
4 wires plus ground
Current:
Power factor:
0.8 lagging
Total harmonic distortion
(THD):
< 2% (linear load)
< 4% (for 100% non-linear load
with a crest factor of up to 3.5)
Dynamic regulation:
± 0.5% for balanced load
± 2.5% for 100% unbalanced load
Dynamic response:
± 5% for 100% step load change
Overload:
125% of rated load for 10 minutes
150% of rated load for 1 minute
DC ratings
Battery voltage:
545 Vdc float
480 Vdc nominal
390 Vdc minimum
Height:
1,905 mm (75”)
Depth:
815 mm (32”)
Width:
See Table 1-1
Weight:
See Table 1-1
Finish:
MGE light gray
