CHARGING THE BATTERY PACK
“Low Battery” will appear on the screen when the battery is low and needs
recharging. The battery can be charged while attached to the unit as follows:
With the Battery Pack attached, insert the small end of the AC adapter into the DC
IN jack on the side of the unit. Insert the other end (with the 2 blades) into a
conveniently-located AC outlet having 120V AC, 60Hz. The CHARGE indicator on
the battery will light red as the battery is charging and green when charging has
completed. Disconnect the AC adapter plugs when charging has finished.
NOTE:
• Fully charge the Battery Pack for 12 hours before using it for the first time. After
the initial charge, it should take approximately five hours to charge.
• A fully-charged Battery Pack can operate for about 2 hours.
To rotate the screen, twist in a clockwise direction up to
180 degrees as shown in Figure 1. It is suggested that the
screen remains in a perpendicular position while it is
being rotated to avoid scratching or damaging the surface
of the unit. To return the unit to its original position, rotate
the unit in a counter-clockwise direction.
If desired, when the screen is rotated to 180 degrees, you
can fold it over onto the body of the unit as shown in
Figure 2. To secure the screen onto the body of the unit,
tuck the tab on the top of the screen into the hole beneath
the Disc Compartment. To release, press the button next
to the hole.
8
POWER SOURCES (CONTINUED)
ROTATING THE SCREEN
Figure 1
Figure 2
