Memorex MVDP1076 - Manual (Page 21)

20
SETUP MENU (CONTINUED)
4:3/PS: Pan Scan. Select when the unit is connected
to a conventional TV. Video material formatted in the
Pan Scan style is played back in that style (the left
and right edges are cut off).
4:3/LB: Letter Box. Select when the unit is
connected to a normal TV. Wide-screen images
are shown on the screen with a black band at the
top or bottom.
16:9: Select when the unit is connected to a wide-
screen TV.
1
NTSC: Select when using an NTSC TV.
PAL: Select when using a PAL TV.
AUTO: Select AUTO only if your TV
supports both formats, the output signal
will follow automatically the video
format on the DVD disc.
IMPORTANT: In the USA, the standard
is NTSC.
1
VIDEO SETUP MENU:
Press the SETUP button to enter the menu, select VIDEO using the Navigation (√,®)
buttons, then press the ENTER button to select it. Select/change the Setup option as
described on page 18.
AUDIO SETUP MENU:
Press the SETUP button to enter the menu, select AUDIO using the Navigation (√,®)
buttons, then press the ENTER button to select it. Select/change the Setup option as
described on page 18.
TV SHAPE (TV DISPLAY) TV SYSTEM
Select the desired Digital Out for coaxial
audio transmissions:
RAW: Select to use the coaxial for Dolby
Digital Audio.
PCM: Select for two channel Digital mode.
Selects the Left and Right channel for stereo
audio output.
1
DIGITAL OUT
