AC CONNECTION
Insert the small end of the AC adapter
into the DC IN jack (located on the
side of the unit) and connect the other
end to a wall outlet having 120V AC,
60 Hz.
AC Adapter, DC 9V Z
NOTES:
• Use the enclosed AC adapter for
this product only.
• Remove both the DC plug and the AC-IN plug to disconnect the AC adapter when
not using.
BATTERY PACK INSERTION/REMOVAL
Follow the diagram below to insert or remove the Battery Pack.
7
POWER SOURCES
TO REMOVE: Press the PUSH (Release)
button, then slide the Battery Pack out and
down.
TO INSERT: Align the tabs from the Battery
Pack into the holes on the bottom of the main
unit. Then, slide the Battery Pack into the
main unit until it clicks into place.
2 1
