25
12. Technical Data
✍
RF input range, F-socket input
Input frequency range 950 . . .2050 MHz
Input impedance: 75
Ω
Video: Gain adjustable -3 . . .+4dB
Frequency range 20Hz . . .5,5 MHz
SAT signal also available at the SCART socket while viewing
terrestrial programs.
Sound: MONO / DUAL / STEREO
Sound carrier frequency: 5,00 . . . 9,99 MHz
Stadardized carrier frequencies are pre-programmed.
Channel bandwidth: 130KHz / 180 KHz / 280 KHz / 380 KHz
Deemphasis: 50 µs, 75 µs, J 17 and PANDA
Power consumption
• of the SAT module: max. 16 W
Timers
8 timers can be programmed up to two months in advance.
Aerial control
LNC voltages: 12 V . . . 19 V „Off“
22 kHz signal On / Off
Relay supply: On / Off
Polarizer control current - 60mA . . .+60mA
All settings can be stored individually for each program position
with the aid of menus.
The power supply sources are short-circuit proof and switch off
if the load is too high. They are switched on again when the
overload is removed. See also the Alignment Instructions.
13. Accessories
• Aerial positioner connection cable
7928-2 Order No. 879 28 02
• SAT-adapter (polarizer / relay)
6228-1 Order No. 862 28 01
