BEFORE USE NAMES OF PARTS
CHECKING THE UNIT AND SUPPLIED ACCESSORIES
Before use, check that the main unit and supplied accessories given below are assembled.
• Anamorphic lens x 1
• Lens Slider x 1
• Base plate x 1
• AC/DC adapter x 1
• AC power cord (for U.S.A.) x 1
• AC power cord (for Europe) x 1
• AC power cord (for Japan) x 1
• Trigger cable
• Mounting screws (machine screw (M3 x 8) x
6, hexagon head bolt (M8 x 10) x 2, decorative
screws (M3 x 8) x 2)
• Washers x 2 (for 3-mm screws x 2, for 8-mm
screws x 2)
• Spring washers x 2
• User’s guide x 1
• Warranty card
U.S.A. x 1
Canada x 1
Japan x 1
Height/tilt adjustment screw (Page. 10)
POWER ON indicator (Page. 3)
Anamorphic lens back/forth
adjustment screw (Page. 10)
Trigger signal input indicator (Page. 3)
Anamorphic lens left/right
adjustment screw (Page. 10)
+5 V DC jack (Page. 3)
Trigger signal input jack
(Page. 3)
Trigger signal output jack
(Page. 13)
Remote control receiver (Page. 4)
Focus adjustment screw (Page. 11)
Lens center mark
