12
MultiFRAD 3000-Series User Guide
Technical Specifications
• Provides access to frame relay networks for SLIP, PPP, async and HDLC sync devices.
• Trunk and Data ports may be configured as EIA-232 or V.35
• Trunk Speeds up to T1/E1 synchronous
• 4MB DRAM
• 1MB of flash memory
Ethernet Port
• One Ethernet Interface - 10Base-T (twisted Pair) RJ-45 connector
Command Port
• Single 19.2Kbps asynchronous Command Port with a DB-25 female connector
Composite Link (external)
• Access Rate: 1.544M bps (T1) or 2.048M bps (E1) sync on DTE-type RS232 or V.35 interface.
Channel Connectors
• 6 on the FR3060; 10 on the FR3100
• Data Rate: synchronous to 128K bps on RS232/V.35 interface;
asynchronous to 115.2K bps on RS232/V.35 interface.
Electrical/Physical
• Operating Environment: 32-104 o F (0-40 o C); 95% non-condensing humidity
• Power Requirements: 100-250V AC at 50/60 Hz
• Dimensions: 17.4” wide x 3.75” high x 8” deep
44.2 cm wide x 8.9 cm high x 20.3 cm deep
• Weight: 7.4 lbs.
3.4 kg
Requirement
• PC with Windows 3.1x/95/NT, Terminal/Dumb Terminal @19200 for menu driven local
configuration, or Remote Configuration via web browser or Telnet.
