12 Placement
Changing Woofer Orientation
When installing the Dynamo 1000 in a cabinet it is rec-
ommended that the subwoofer be converted to a front
firing configuration. (see figure 9).
1 Prepare a flat surface with a blanket to protect the
Dynamo 1000's finish. Unplug signal and power connec-
tions. Remove the grill cloth.
2 Carefully lay the Dynamo 1000 on its side. Using a coin,
unscrew the attached feet. (see figure 10).
3 Change the location of the four feet.
4 Using a coin, reinstall the feet (see figure 10).
Please note, 90° RCA adaptors may be required to
make signal connections. Two 90° RCA adaptors are
included with the Dynamo 1000 subwoofer.
Figure 10. To change woofer orientation, use a coin to unscrew the
attached feet, change location, and reinstall.
Figure 9. The Dynamo 1000 is capable of both front-firing and down-firing woofer orientations.
