MartinLogan Stage ESL Series - Manual

The Loudspeaker Technology Company
www.martinlogan.com ©2009 MartinLogan, Ltd. All rights reserved.
Application:
Home theater center/front/surround
ideal for large and medium rooms.
Incorporating a state-of-the-art
XStat™ electrostatic panel and
a highly sophisticated Vojtko™
crossover, Stage takes versatility to
the next level, working as a main
or surround speaker, mounted
on- or off-wall, horizontally or
vertically.
Key Features:
• HD-XStat™ (hybrid dynamic)
CLS™ electrostatic transducer
• Dual 6.5-inch high-resolution
aluminum cone woofers
• Precision Vojtko™ crossover
• Low-voltage power supply
• Multi-mount pivoting bracket/stand
S
tage ™
ON-WALL/OFF-WALL THEATER CENTER/FRONT/SURROUND
FiNiSH OpTiONS
ULTimATE-pERFORmANCE ELECTROSTATiC CENTER CHANNEL
Designed to serve primarily as the center in a home theater incorporating
MartinLogan electrostatic speakers, Stage is versatile enough to handle
left, right, and surround channel duties as well. Dual 6.5-inch aluminum-cone
woofers and an advanced Vojtko™ crossover perfectly integrate a solid
bass performance with the astonishingly transparent, detailed midrange and
treble provided by the XStat™ transducer. A single-pivot bracket/stand
facilitates set-top, shelf, on-wall, or on-floor placement.
Frequency Response 69–22,000 Hz ± 3dB
Sensitivity 90 dB/2.83 volts/meter
Impedance 4 Ohms/2.9 @ 20kHz
Crossover Frequency 450, 2700 Hz
High Frequency Driver 1” (2.54cm) neodymium
soft dome
Mid Frequency Driver CLS™ XStat™ electrostatic
Low Frequency Drivers Two 6.5” (16.5cm)
aluminum cone
Power Handling 250 watts
Weight 39 lbs. (17.7kg)
Dimensions (mounting stand beneath, HxWxD) 12” x 34.6” x 10.3”
(30.4 x 87.9 x 26.1cm)
Black Ash
Natural
Cherry
maple
Dark
Cherry
Visit configurator.martinlogan.com to
explore the full range of finish options.
ESL
SERIES
