TEST SETUP & TESTING 5 - 1
CHAPTER 5
TEST SETUP & TESTING
Typical Test Setup
Carry out the following instructions before testing:
• Check that you have a fully charged battery.
Not required when using Battery Eliminator (P/N: 66007029002) and RF radio
rear antenna adapter (P/N: 66007029001).
• For testing the radio, a special Battery Eliminator (P/N: 66007029002) and RF
radio rear antenna adapter (P/N: 66007029001) with RF cable is required.
• Detach the antenna from the radio.
• Connect the special RF adapter to the rear side antenna connector of your
radio and fix it by screwing the wing nut into the antenna thread.
• Connect the other side of the cable to the N-type RF Connector of the IFR
using a N-type-to-SMA-adapter.
• Connect the power supply to the battery eliminator wires.
Any level 3 repairs can deeply affect the performance of the
MTP810 Ex and may cause a new tuning procedure. This tuning
procedure can be applied by certain authorised Motorola depots
where the appropriate TEST & TUNE EQUIPMENT is
available.The appropriate TEST & TUNE EQUIPMENT is a
special automated test equipment which is only available at
some Motorola factories and Motorola repair centers.
