Model Series 462 Thru 465
Ref.
No.
Part No.
Part Description
1.
728-0175
Pop Rivet
2.
731-1899
Chipper Chute
3.
735-0249
Chute Flap
4.
781-0633
Chute Flap Strip
5.
681-0095
Chipper Chute †
6.
681-0068A
Chipper Chute Assembly
7.
710-0751
Hex Cap Screw 1/4 -20 x.620
8.
712-3027
Hex Lock Nut 1/4-20
9.
710-0106
Hex Cap Screw 1/4-20 x 1.25
10.
736-0173
Flat Washer.28 ID x.74 OD
11.
736-0242
Bell Washer.340 ID x.872 OD
12.
712-3010
Hex Nut 5/16-18
13.
749-1004
Support Brace
15.
714-0149B
Cotter Pin
16.
681-0048
Wing Knob 5/16-18
17.
681-0094
Discharge Chute Assembly
18.
711-0835
Clevis Pin
19.
781-0457
Flail Screen
20.
726-0211
U-Nut 5/16-18
21.
750-0793
Spacer
22.
712-3027
Hex Lock Nut 1/4-20
23.
712-3004A
Hex Lock Nut 5/16-18
24.
736-0119
Lock Washer 5/16
25.
681-0184
Frame
26.
710-0805
Hex Cap Screw 5/16-18 x 1.50
27.
736-0170
Bell Washer 5/16 x 1.0
28.
681-0117
Inner Impeller Housing Assembly
29.
710-3008
Hex Cap Screw 5/16-18 x.75
30.
710-0157
Hex Cap Screw 5/16-24 x.75
31.
781-0490
Chipper Blade
32.
710-1054
Hex Cap Screw 5/16-24 x 1.0
33.
681-0030
Impeller Assembly
34.
736-0119
Lock Washer 5/16
35.
712-0411
Hex Lock Nut 5/16-24
36.
781-0735
Pin Clip
37.
719-0329
Flail Blade
38.
711-0833B
Clevis Pin
39.
715-0166
Pin
40.
736-0247
Flat Washer 3/8 x 1.25
41.
742-0571
Shredder Blade
42.
710-1254
Hex Cap Screw 3/8-24 x 2.25
43.
738-0813
Axle Assembly
738-0814
Axle Assembly †
44.
750-0786
Spacer
45.
734-1597A
Wheel Assembly 10.0 x 4.0
46.
726-0214
Push Cap
47.
734-1600
Wheel Assembly 10.0 x 2.5 †
48.
681-0004A
Outer Impeller Housing Assembly
49.
710-0825
Hex Cap Screw 1/4-20 x 3.75
50.
781-0515
Support Bracket
51.
781-0574
Support Plate
52.
681-0104
Impeller Bracket Assembly
53.
732-0306
Compression Spring 1.75
54.
736-0117
Flat Washer
55.
714-0104
Cotter Pin
56.
736-0264
Flat Washer.330 ID x.630 OD
57.
710-0376
Hex Cap Screw 5/16-18 x 1.0
59.
736-0362
Flat Washer.320 ID x 1.25 OD
60.
712-0429
Hex Lock Nut 5/16-18
61.
731-1710
Hopper Collar
62.
681-0123
Hopper Bracket Assembly
63.
711-1128
Lock Rod
64.
731-1707
Hopper Assembly
65.
710-3008
Hex Cap Screw 5/16-18 x.75
66.
764-0199A
Bag (Not Shown)
67.
731-1617
Tamper Plug (If Equipped)
Ref.
No.
Part No.
Part Description
† Model 462 Only
