DCA85USJ2 60 HZ GENERATOR • OPERATION AND PARTS MANUAL — REV. #1 (03/22/11) — PAGE 87
FUEL TANK ASSY.
NO. PART NO. PART NAME QTY. REMARKS
1 M2363000902 FUEL TANK 1
1-1 0605505070 FUEL TANK CAP 1
1-2 0605501073 FUEL SENDER UNIT 1
1-2A 0605516090 GASKET 1
2 M2363200404 TANK BAND 3
3 M2363200904 TANK BAND 3
4 M9310500104 SUPPORTER SHEET 6
5 0016908020 HEX HEAD BOLT 6
6 0207008000 HEX NUT 6
7 0222101000 TANK SHEET 5
8 0191302140 VENT HOSE 1
9 0605515109 HOSE BAND 2
10 0602042601 RETURN PIPE 19
11 0191301000 SUCTION HOSE 1
12 0191300700 RETURN HOSE 1
13 0605515109 HOSE BAND 4
14 0605511190 PICKUP ELBOW 1
15 0605512190 HOSE JOINT 1
16 0605512191 HOSE JOINT, 1/4-18 NPT 1
