DCA85USJ2 60 HZ GENERATOR • OPERATION AND PARTS MANUAL — REV. #1 (03/22/11) — PAGE 77
ENGINE AND RADIATOR ASSY.
NO. PART NO. PART NAME QTY. REMARKS
1 M2923200094 ENGINE, JOHN DEERE 4045HF285 1
1A R135680 FAN BELT ....................................................1 ................REPLACES P/N 0602015233
1-1 RE504836 CARTRIDGE, OIL FILTER ..........................1 ................REPLACES P/N 0602041292
1-2 RE529643 CARTRIDGE, PRIMARY FUEL FILTER ......1 ................REPLACES P/N 0602042596
1-3 RE522878 CARTRIDGE, FINAL FUEL FILTER ............1 ................REPLACES P/N 0602042597
2 0602060008 BLOWER FAN 1
3 0602061000 FAN SPACER 1
4 0012110095 HEX HEAD BOLT 4
5 0042510000 WASHER, LOCK 4
6 M2303200303 ENGINE FOOT 2
7 0010312030 HEX HEAD BOLT 6
8 0040012000 WASHER, LOCK 6
9 0605000009 RUBBER SUSPENSION 2
10 0030012000 HEX NUT 2
11 0040012000 WASHER, LOCK 2
12 C0923200124 RADIATOR 1
12-1 0602011029 CAP, RADIATOR 1
13 0016910025 HEX HEAD BOLT 2
14 M9200100904 PLUG 1
15 0150000016 O-RING 1
16 M3310501803 RADIATOR HOSE 1
17 M3310501903 RADIATOR HOSE 1
18 0605515148 HOSE BAND 3
19 0605515147 HOSE BAND 1
20 M2313300203 FAN BRACKET 1
21 0016910025 HEX HEAD BOLT 4
22 0601822794 FAN MOTOR 2
23 0016910025 HEX HEAD BOLT 8
24 0602046582 AIR CLEANER 1
24A 0602046365 ELEMENT, AIR CLEANER 1
25 0602040651 INDICATOR, AIR CLEANER 1
26 0602040554 AIR CLEANER BAND 1
27 0016908030 HEX HEAD BOLT 2
28 M2373101703 HOSE, AIR CLEANER 1
29 M2373101803 HOSE, AIR CLEANER 1
30 0605515146 HOSE BAND 1
31 0605515197 HOSE BAND 2
32 0191600530 BLOWBY HOSE 1
33 0605515149 HOSE BAND 1
34 0602022563 ADAPTER....................................................1 ................S/N 8400995 AND BELOW
34 0602022586 ADAPTER....................................................1 ................S/N 8400996 AND ABOVE
35 0602022561 90 DEGREE ELBOW ..................................1 ................S/N 8400995 AND BELOW
35 0602022579 90 DEGREE ELBOW ..................................1 ................S/N 8400996 AND ABOVE
36 0603306590 CONNECTOR .............................................1 ................S/N 8400995 AND BELOW
36 0603306597 CONNECTOR .............................................1 ................S/N 8400996 AND ABOVE
37 0603300285 LOCKNUT ...................................................1 ................S/N 8400995 AND BELOW
37 0603300286 LOCKNUT ...................................................1 ................S/N 8400996 AND ABOVE
