Pre-power testing - recording resistance values – Motorola PTP 500 User Manual
Page 14
Record the information listed in Table 2. This information will be useful if there is a need to
contact Motorola Support or to identify future changes in the installation.
Table 2 : Record of Installation Measurements
User Notes
Measure
Resistance
Between Pins
Measured
Resistance
Value
LOCAL
1&2
3&6
4&5
7&8
1&3
4&7
1&8
1&ODU Ground
8&ODU Ground
Measured
Resistance
Value
REMOTE
Pre-Power Testing - Recording Resistance Values
IP Address LOCAL
Link Name LOCAL
MAC Address LOCAL
14
IP Address REMOTE
Link Name REMOTE
MAC Address REMOTE
