4
Features
The V-R241-DLW (Dual Link / Waveform) monitor is the latest addition to Marshall's expanding line of IMD-equipped
monitors.
■ 1920 x 1200 Full Resolution 24” Panel
The V-R241-DLW features an all-digital TFT-
MegaPixel active matrix LCD system with 1920x1200
native resolution. The LCD panel features a
brightness of 400 cd/m
2
and a 1000:1 contrast ratio
making it ideal in a variety of environments and
lighting conditions.
■ Multi mode, Vectorscope and Waveform Monitor
mode
The DLW monitor series includes a real-time
Waveform monitor and Vectorscope along with
support for SDI, HD-SDI, 3G-SDI and Dual Link SDI.
With the monitor in Multi mode, the monitor will break
into four quadrants and display Signal Input
information (Link Status), Embedded Audio levels, a
Waveform monitor, a Vectorscope and live video
simultaneously. Additional layouts provide the ability
to view the Waveform monitor, Vectorscope, SDI Link
status and Video individually.
■ Closed Captioning Decoding
The DLW monitor allows for decoding of Closed
Captioning in the EIA-608 or EIA-708.
■ In-Monitor Display
In-Monitor Display allows on-screen text and tally
indication, controlled locally or remotely via a variety
of industry standard protocols.
■ OSD Features (On Screen Display)
Embedded time code and an embedded audio
presence indicator can be displayed on the screen in
a variety of configurations. Closed Caption presence
indication is also provided for 608/708 captions.
■ Advanced Features
Color temperature adjustment, aspect ratio settings,
blue-only mode, and monochrome mode are a few of
the advanced features allowing the V-R241-DLW to
be at home in any broadcast environment. Pixel-to-
Pixel mode also allows native display of any incoming
image format.
■ Four User-Definable Function Buttons
Four user-definable function buttons allow quick
access to numerous settings and features including
aspect ratio, monochrome mode, color temperature,
and more.
