16 Rear Panel

COAXIAL

ANT.

Power Cord
Connect to a standard AC outlet (

120V/60Hz).

COAXIAL Jack
(Digital Audio Out) (orange)
Connect this jack to a Digital Stereo using a digital audio coaxial
cable (not supplied). Use this connection if the Stereo has Dolby
Digital compatibility and has a Digital Coaxial Audio In jack.You
may also use this connection when connecting the TV/DVD to a
Mini-Disc or Digital Audio Tape deck. See page

10.

ANT. Jack
(Antenna In)
Connect an antenna or Cable TV signal here.This brings TV
channels to the TV/DVD. If you do not connect an antenna or
Cable TV signal to the TV/DVD (or connect to a Cable
Box/Satellite Receiver through this jack), you will not receive any
TV channels. See page eight.
